Caterpillar Customer Communication Module PC Page 39

Getting Started
8-5
Section
8
informs you of the problem that is occurring. Occ. (occurrences)
column informs you of the number of times that the problem
occurred. The columns marked First and Last indicate the first and
last ECM hour that the problem occurred.
The list of codes is grouped according to the ECM that it is retrieved
from, and they appear ordered chronologically by the most recent
ECM hour of last occurrence. The ECM names appear as subtitles in
the list. On the same line as the ECM subtitle, the number of ECM
diagnostic clock hours displays. These hours represent the time that
the ECM has been connected and running.
Include All ECMs Check Box
When the Include All ECMs check box is checked, logged codes
from all available ECMs are retrieved and displayed. When there is a
single ECM on the data link, this check box is disabled. CCM
Diagnostic Codes are not available.
Pushbuttons
The pushbuttons available in the Logged Diagnostic Codes screen
are:
•= Clear
•= Print
Note: See “Printing a Document” section 6.
Previous page
Next page
