CAT 72H Pipelayer Operation and Maintenance Manual Page 37

Operation and Maintenance Manual
37
WEBM1000 Product Information Section (D6T LGP (OEM))
Identification Information
29
Illustration 29
The Information Plate is on the engine valve cover.
The following information is stamped on the
Information Plate: engine maximum altitude,
horsepower, high idle, full load rpm, fuel settings
and other information.
The serial number plate for the dozer blade is
at
tached t
o the back side of the dozer, if equipped.
Certification
CE Mark
This plate is positioned on the PIN plate on the left
side of the front frame.
For machines that are compliant to “2006/42/EC”,
the following infor
mation is stamped onto the “CE”
plate.
30
Illustration 30
CE plate
For quick reference, record this information in the
spaces that are provided below.
• Engine Power of primary engine (kW)
• Engine Power for additional engine (kW) (if
equipped)
• Typical operating weight of machine for European
market (kg)
• Year of construction
• Machine Type
For machines that are compliant to “1998/37/EC”,
the following information is stamped onto the “CE”
plate.
31
Illustration 31
For quick reference, record this information in the
spaces that are provided below.
• Engine Power of primary engine (kW)
• Typical operating weight of machine for European
market (kg)
•Year
Structure certification (ROPS)
m
WARNING
Structural damage, an overturn, modification,
alteration, or improper repair can impair this
structure's protection capability thereby voiding
this certification. Do not weld on or drill holes in
the structure. This will void the certification.
Consult your Cat dealer to determine this
structure's limitations without voiding its
certification.
The protective structure certification is located on
the outside of the left post.
