CAT 72H Pipelayer Operation and Maintenance Manual Page 8

Operation and Maintenance Manual
8
Safety Section (D6T LGP (OEM)) WEBM1000
Safety Messages
Replace any safety message that is damaged or
missing. If a safety message is attached to a part of
the machine that is replaced, install a safety
message on the replacement part. Any Caterpillar
dealer can provide new safety messages.
Do Not Operate 1
Safety message (1) is positioned on the upper ledge
of the left-hand console of the operator station.
m
WARNING
Do not operate or work on this equipment unless
you have read and understand the instructions
and warnings in the Operation and Maintenance
Manual. Failure to follow the instructions or heed
the warnings could result in injury or death.
Contact any Cat dealer for replacement manuals.
Proper care is your responsibility.
