WEBM1000 Operation Section (D6T LGP (OEM))
Machine Operation
Data Broadcasts
Data concerning this machine, the condition of the
machine, and the operation of the machine is being
transmitted by Product Link to Caterpillar and/or Cat
dealers. The data is used to serve the customer
better and to improve upon Caterpillar products and
services. The information transmitted may include:
machine serial number, machine location and
operational data, including but not limited to: fault
codes, emissions data, fuel usage, service meter
hours, software and hardware version numbers and
installed attachments.
Caterpillar and/or Cat dealers may use
this
info
rmation for various purposes. Refer to the
following list for possible uses:
• Providing services to the customer and/or the
mac
hine
•
Checking or maintaining Product link equipment
• Monitoring the health of the machine or
performan
ce
• Helping maintain the machine and/or improve the
efficien
cy of the machine
• Evaluating or improving Caterpillar products and
services
• C
omplying with legal requirement
s and valid court
orders
• Performing market research
• Offering the customer new products and services
Caterpillar may share some or all of the collected
information w
ith Caterpillar affiliated companies,
dealers, and authorized representatives. Caterpillar
will not sell or rent collected information to any other
third party and will exercise reasonable efforts to
keep the information secure. Caterpillar recognizes
and respects customer privacy. For more
information, please contact your local Cat dealer.
Operation in a Blast Site
If the machine is required to work within 12 m (40 ft)
of a blast site, then Product Link 121SR system or
the Product Link 522/523 system should be
disabled in compliance with applicable legal
requirements. One of the following are suggested
methods in order to disable the Product Link 121SR
system or the Product Link 522/523 system: (a)
Install a Product Link disconnect switch in the
machine cab that will allow the Product Link 121SR
system or the Product Link 522/523 system module
to be shut off. Refer to Special Instruction,
REHS2365 “An Installation Guide for the Product
Link PL121SR and for the PL300” and Special
Instruction, REHS2368 “Installation Procedure For
Product Link PL522/523 (Cellular)” for more details
and installation instructions. Or, (b) Disconnect the
Product Link 121SR system or the Product Link
522/523 module from the main power source by
disconnecting the wiring harness at the Product Link
module.
The following Product Link 121SR system and the
Pr
oduct Li
nk 522/523 system specifications are
provided in order to aid in conducting any related
hazard assessment and to ensure compliance with
all local regulations:
• The transmit power rating for the Product Link
121
SR tr
an
smi
tter is 5 to 10 W.
• The operating frequency range for the Product
Link 121S
R system is 148 to 150 MHz
• The transmit power rating for the Product Link
522/523 t
ransmitter is approximately 1 W.
• The operating frequency range for the Product
Link 522/
523 system is 824 to 849 MHz, 880 to
915 MHz, 1710 to 1785 MHz, and 1850 to 1910
MHz.
Consult your Cat dealer if there are any questions.
Information for the initial insta
llation
of the Product
Link 121SR system is available in Special
Instruction, REHS2365 “An Installation Guide for the
Product Link PL121SR and for the PL300”.
Information for the initial installation of the Product
Link 522/523 system is available in Special
Instruction, REHS2368 “Installation Procedure For
Product Link PL522/523 (Cellular)”.
Operation, configuration and troubleshooting
inf
orm
ation for the Product Link 121SR system can
be found in the Systems Operation, Troubleshooting,
Testing and Adjusting, RENR7911, “Product Link
121/321”.
Operation, configuration and troubleshooting
inf
orm
ation for the Product Link 522/523 system
can be found in the Systems Operation,
Troubleshooting, Testing and Adjusting, RENR8143,
“Product Link - PL522/523”.
