WEBM1000 Safety Section (D6T LGP (OEM))
Safety Messages
Seat Belt (2)
Safety message (2) is located on the right console to
the right of the dozer control.
m
WARNING
A seat belt should be worn at all times during
machine operation to prevent serious injury or
death in the event of an accident or machine
overturn. Failure to wear a seat belt during
machine operation may result in serious injury or
death.
Do Not Weld on the ROPS (3)
Safety message (3) is positioned on the vertical
support of the outside left ROPS post.
m
WARNING
Structural damage, an overturn, modification,
alteration, or improper repair can impair this
structure's protection capability thereby voiding
this certification. Do not weld on or drill holes in
the structure. This will void the certification.
Consult your Cat dealer to determine this
structure's limitations without voiding its
certification.
This machine has been certified to the standards
that are listed on the certification plate. The
maximum mass of the machine, which includes the
operator and the attachments without a payload,
should not exceed the mass on the certification
plate.
A typical example of the certification plate is shown
a
bove.
Ref
er to Operation and Maintenance Manual,
“Guards (O
perator Protection)” for more information.
