CAT 72H Pipelayer Operation and Maintenance Manual Page 95

Operation and Maintenance Manual
95
WEBM1000 Operation Section (D6T LGP (OEM))
Machine Operation
11. Select an intermediate speed in the following
manner:
a. Set the engine speed to high idle.
b. Select the desired engine speed with the
decele
rator (2).
c. Push in on the throttle control switch and hold
for 3 se
conds in order to lock in the engine
speed. This speed is now the maximum
operating speed.
12. Chan
ge an intermediate speed
in the following
manner:
a. Push in the top part of the throttle control
switch a
nd hold for 3 seconds. Then, release
the switch. The rpm ramps up from the current
setting.
b. Push in th
e bot
tom part of the throttle control
switch and hold for 3 seconds. Then, release
the switch. The rpm ramps down from the
current setting.
13. Use
the differential steering control in order to
tur
n the machine.
14. Drive the machine forward for best visi
bility and
for control.
Changing Direction and Speed
NOTICE
For operator comfort and maximum service life of
power t
rain components, deceleration and/or braking
is recommended before any directional shifts are
made.
Speed changes and directional changes at full
engine speed are possible.
1. In order to decrease engine speed, push down
on th
e decelerator pedal (2).
2. When the machine slows, shift the transmission
to the desir
ed direction with direction selector
(4).
3. In
crease the engine speed by releasing the
decele
rator pedal (2).
4. Select the desired speed with speed range
select
or (5).
Battery Disconnect Switch
132
Illustration 132
The battery disconnect switch is on the left side of
the machine behind the access door in front of the
battery box.
On – Insert the key, and turn the key
clockwise in order to activate the
electrical syst
em. The switch must be ON
before you start the engine.
Off – Turn the key counterclockwise in
order to shut off the entire electrical
system.
Remove
the key when you exit the machine
overnight or wh
en you exit the machine for an
extended period. Also, remove the key when you
service the electrical system.
NOTICE
Never move the battery disconnect switch to the OFF
position while t
he engine is operating. Serious
damage to the electrical system could result.
