Wide shoes accentuate the effects of

impact conditions. Machines with single

grouser shoes are more susceptible to

higher impact effects than those with

lower profile or multi-grouser shoes.

Packing

Packing describes any condition where

underfoot material sticks to or packs between

moving undercarriage components. It has

two major effects. First, it can prevent mat-

ing parts from properly engaging each

other causing interference, high loads and

increased wear rates. The best examples of

this effect is sprocket teeth packing, or

packing between shoe and bushings, caus-

ing the teeth to engage the bushings under

interference.

The second major effect of packing is it

binds abrasive particles to moving compo-

nents thus increasing the wear rate. The

best example of this is a sand-clay mixture

packed around idlers, carrier and track

rollers causing constant abrasion when

these components turn. The result is

similar to a grinding or polishing wheel.

Parts subjected to this effect are usually

polished smooth.

Severe cases of packing will prevent the

rollers, particularly carrier rollers, from

turning. Then links must slide across roller

treads causing flat spots which are easily

recognizable.

Packing materials vary widely and extend

far beyond clay and mud that are normally

associated with the above effects. The fol-

lowing list of materials can result in one or

both of the major effects listed above.

Obviously, the moisture content of most of

these materials helps determine its sticki-

ness and its compactability. Many under-

foot conditions are composed of various

combinations of these materials and the

effect may be cumulative. Packing materi-

als fall into two categories; (A) those that

can usually be extruded (squeezed out)

from between the parts when wet and (B)

those which cannot be extruded with the

pressures and opening sizes normally avail-

able in track type machines.

Packing Materials

A Extrudable (when wet)

Sanitary Landfill (garbage)

Silt soils

Clay soils

Sandy soils

Snow and ice

Metallic ores (taconite)

Non-metallic ores (gypsum)

B Non-extrudable

Sanitary Landfill (garbage)

Branches, twigs and brush

Stones, rocks and gravel

Demolition debris

Sod-like materials

Generally, packing effects cannot be con-

trolled except by constant cleaning or

removal.

The most common modification to under-

carriage components or use of option attach-

ments involves providing Trapezoidal

openings for the packing type material to

extrude (squeeze) or fall out, thus reliev-

ing the pressure. These modifications or

attachments should only be used in the

presence of extrudable type materials.

(List A above)

1. Trapezoidal Openings in shoes.

Caterpillar recommends that track shoes

with trapezoidal openings be used in the

presence of extrudable type material

(see list A above). Track Shoes with

trapezoidal openings are available for

most models from Caterpillar. The pro-

cedure for dealers or users to cut trape-

zoidal openings in shoes is described in

Information release memo UC89-17

dated Oct. 4, 1989.

2. Roller guards should not be used in

packing type materials except when

rocks could enter between the rollers

and cause crushing damage. Roller

guards prevent most materials from

extruding or falling out and cause more

damage than they prevent.
