Rules Recap

1. Swap rollers if percent worn of most

worn exceeds percent worn of least

worn by more than 1.3:1 ratio.

2. Swap rollers when the average percent

worn is close to 50 percent (or 60 per-

cent if target is destruction).

3. Swap most worn with least worn of

same flange type; swap second most

worn with second least worn of same

flange type, etc.

4. Take advantage of both track and/or

roller swaps from left to right side of

machine to further balance total system.

The same principle can be applied to

machines with four carrier rollers or

four idlers to balance their fore and aft,

or left and right wear rates.

Note: See other references to roller swap-

ping guidelines specific to overall under-

carriage management alternatives in the

Management/Merchandising and Elevated

Sprocket Tractor Section.
