Caterpillar Custom Track Service Handbook Page 521

Service Handbook

Page of 826

/ 826

Bushings for Sealed Track

External Wear

Grease Lubricated Track

Only use for 320 FM

Allowable Wear

Caliper Lesser Greater Ultrasonic

Inches (mm) % Worn % Worn Inches (mm)

2.56 (65.0) 0 0 0.51 (13.0)

2.55 (64.8) 5 4 0.50 (12.7)

2.54 (64.5) 10 8 0.49 (12.4)

2.53 (64.3) 15 12 0.48 (12.2)

2.52 (64.0) 20 16 0.47 (11.9)

2.51 (63.8) 25 20 0.46 (11.7)

2.50 (63.5) 30 24 0.45 (11.4)

2.49 (63.2) 35 28 0.44 (11.2)

2.48 (63.0) 40 32 0.43 (10.9)

2.47 (62.7) 45 36 0.42 (10.7)

2.46 (62.5) 50 40 0.41 (10.4)

2.45 (62.2) 55 44 0.40 (10.2)

2.44 (62.0) 60 46 0.39 (9.9)

2.43 (61.7) 65 48 0.38 (9.7)

2.42 (61.5) 70 50 0.37 (9.4)

2.41 (61.2) 72 52 0.36 (9.1)

2.40 (61.0) 74 54 0.35 (8.9)

2.39 (60.7) 76 56 0.34 (8.6)

2.38 (60.5) 78 58 0.33 (8.4)

2.37 (60.2) 80 60 0.32 (8.1)

2.36 (59.9) 82 62 0.31 (7.9)

2.35 (59.7) 84 64 0.30 (7.6)

2.34 (59.4) 86 66 0.29 (7.4)

2.33 (59.2) 88 68 0.28 (7.1)

2.32 (58.9) 90 70 0.27 (6.9)

2.31 (58.7) 92 72 0.26 (6.6)

2.30 (58.4) 94 74 0.25 (6.3)

2.29 (58.2) 96 76 0.24 (6.1)

2.28 (57.9) 98 78 0.23 (5.8)

2.27 (57.7) 100 80 0.22 (5.6)

2.26 (57.4) 102 82 0.21 (5.3)

2.25 (57.2) 104 84 0.20 (5.1)

2.24 (56.9) 106 86 0.19 (4.8)

2.23 (56.6) 108 88 0.18 (4.6)

2.22 (56.4) 110 90 0.17 (4.3)

2.21 (56.1) 112 92 0.16 (4.1)

2.20 (55.9) 114 94 0.15 (3.8)

2.19 (55.6) 116 96 0.14 (3.6)

2.18 (55.4) 118 98 0.13 (3.3)

2.17 (55.1) 120 100 0.12 (3.0)

2.16 (54.9) 102 0.11 (2.8)

2.15 (54.6) 104 0.10 (2.5)

2.14 (54.4) 106 0.09 (2.3)

2.13 (54.1) 108 0.08 (2.0)

2.12 (53.8) 110 0.07 (1.8)

2.11 (53.6) 112 0.06 (1.5)

2.10 (53.3) 114 0.05 (1.3)

2.09 (53.1) 116 0.04 (1.0)

2.08 (52.8) 118 0.03 (0.8)

2.07 (52.6) 120 0.02 (0.5)

Undercarriage Code: 567

520

320 FM — 7.50" (190 mm)

Excavators

10.Exc.(488-607) 7/14/03 7:32 AM Page 520
