CAT D3K, D4K and D5K Track-Type Tractors Operation and Maintenance Manual Page 10

Operation and Maintenance Manual
10 SEBU8213-04
Safety Section
Safety Messages
High Pressure Fuel Lines (6)
Safety Message (6) is located on the left side of the
engine on the high pressure fuel rail.
g01381180
Contact with high pressure fuel may c ause fluid
penetration and burn hazards. High pressure fu-
el spray may cause a fire hazard. Failure to fol-
low t hese inspection, maintenance and service in-
structions may cause personal injury or death.
High Pressure C y linder (7)
Safety Message (7) is located on the track adjuster
cover that is on the outside of the track roller frame.
g01357122
High Pressure Cylinder. Do not remove any parts
f
rom the c ylinder until all of the pressure has been
relieved. This will prevent possible personal injury
or death.
Hot Fluid Under Pressure (8)
Safety Message (8) is located under the access door
on the expansion tank filler cap.
g01370913
Pressurized system: Hot coolant can cause seri-
ous burn. To open cap, stop engine, wait until ra-
diator is cool. Then loosen cap slowly to reliev e
the pressure.
