CAT D3K, D4K and D5K Track-Type Tractors Operation and Maintenance Manual Page 50

Operation and Maintenance Manual
50 SEBU8213-04
Operation Section
Machine Operation
System Voltage
g01329052
Illustration 59
Mode 0 System Voltage LCD Screen
The System Voltage screen indicates the current
system voltage.
Service Hour Meter
g01329053
Illustration 60
Mode 0 S ervice Hour M eter LCD Screen
The Service Hour Meter screen indicates the total
operating hours of the machine.
Mode 1 - Steering M odulation Settings
The Mode 1 - Steering Modulation Settings screen
has the following submenus:
Fine
g01328924
Illustration 61
Mode 1 - Steering Mo dulation Settings - Fine LCD Screen
Medium
g
01328926
Illustration 62
Mode 1 - Steering Modulation Settings - Medium LCD Sc reen
Coarse
g01328936
Illustration 63
Mode 1 - Steering Modulation Settings - Coarse LCD S creen
Mode 2 - Implement Modulation Settings
The Mode 2 - Implement Modulation Settings screen
has the following submenus:
Fine
g01328942
Illustration 64
Mode 2 - Implement Modulation - Fine LCD Screen
Standard
g01328946
Illustration 65
Mode 2 - Implem ent Modulation - Standard LCD Screen
Fast
g01328944
Illustration 66
Mo
de 2 - Implement Modulation - Fast LCD Screen
