CAT D3K, D4K and D5K Track-Type Tractors Operation and Maintenance Manual Page 60

Operation and Maintenance Manual
60 SEBU8213-04
Operation Section
Machine Operation
Gauges
g0121137
0
Illustration 86
Hydraulic Oil Temperature (13) – The
gauge indicates the temperature of the
hydraul
ic oil in the hydraulic oil sump for the
steering and implement circuits. If the gauge needle
enters the red zone the hydraulic oil temperature
is exces
sive. The Compact Instrument Cluster will
display a warning. If necessary, reduce the load that
is on the machine until the hydraulic oil temperature
decrea
ses.
Engine Coolant Temperature (14) –
The water temperature regulator regulates
the coo
lant temperatures. If the gauge
needle enters the red zone the coolant temperature
is excessive. Increased temperatures will sound
the wa
rning alarm. Continued operation of the
machine during the sounding of the warning alarm
or the gauge needle in the red zone may damage
the e
ngine. Stop the machine in a safe place and
investigate the cause.
Fuel Level (15) – The fuel level gauge
indi
cates the amount of fuel that remains
in the fuel tank. A gauge needle in the red
zone indicates a low fuel level.
NOTICE
Running out of fuel can cause engine damage. Do not
continue to operate the machine when critically low on
fuel.
Digital Display Window (17)
g0162571
3
Illustration 87
Gauge display (Compac t Instrument Cluster)
g01270291
Illustration 88
“CIC
”Film
Digital display window (17) provides readouts that
show
the following items:
•
Operational hours (service hours)
•
Engine speed (tachometer)
•
Dia
gnostic codes
•
Selected speed and direction
•
Hydraulic Oil Temp
•
Im
plement Control Modes
•
Steering Control Modes
•
System Voltage
•
O
il Pressure
Press up arrow button (18) until the desired function
i
s displayed. Press the right arrow button (18) in order
to access the parameters of the displayed function.
