Parking
i02801552
Leaving the M ach ine
SMCS Code: 7000
g01259039
Illustration 105
1. Use the steps and the handholds when you get
off the machine. Face the machine and use both
hands. Make sure that the steps are clear of
debris before you dismount.
Note: Do not use the angle cylinders as a step.
2. Inspect the engine compartment for debris. Clean
out any debris and any paper in order to avoid a
fire.
3. Turn the key for the battery disconnect switch
to the OFF position. This will help to prevent a
batte ry short circuit and the current draw that is
made by certain components. When the machine
is not operated for an extended period, remove the
key from the battery disconnect switch. Removing
the key will help to protect the machine from
vandalism.
4. Install all vandalism protection locks and
vandalism covers. Lock the doors.
