Battery or Battery Cable - Inspect/Replace
i02801605
Battery or Battery Cable -
Inspect/Repl
ace
SMCS Code: 1401-040; 1401-510; 1401; 1402-040;
1402-510
Personal in
jury may occur from failure to properly
service the batteries.
Batteries
give off flammable fumes that can ex-
plode. Electrolyte is an acid and can cause per-
sonal injury if it contacts the skin or eyes.
Prevent sparks near the batteries. Sparks could
cause vapors to explode. Do not allow jumper c a-
ble ends t
o contact each other or the engine. Im-
proper jumper cable connections can cause an ex-
plosion.
Always wear protective glasses when working
with batteries.
1. TurntheenginestartswitchkeyOFF.Turnallof
the switches OFF.
g01259128
Illustration 112
2. Turn the battery disconnect switch OFF. Remove
the key.
3. Disconnect the negative battery cable from the
disconnect switch.
Note: Do not allow the disconnected battery cable to
contact the disconnect switch.
g01399056
Illustration 113
g014
00107
Illustration 114
There are two ba tteries on this m achine.
(1) P
rimary battery
(2)
Secondary battery
4. Disconnect the negative battery cable at battery
(1)
. The primary battery is located behind the right
side access door.
5. Di
sconnect the positive battery cable at the
battery.
6. Re
movethematandthefloorplate in the cab in
order to access the secondary battery. Perform
steps 4 and 5 in order to disconnect the secondary
ba
ttery.
