CAT D3K, D4K and D5K Track-Type Tractors Operation and Maintenance Manual Page 11

Operation and Maintenance Manual
SEBU8213-04 11
Safety Section
Safety Messages
Improper Connections for Jump
Start Cables (9)
Safety Message (9) is located on the right access
door outside the operator station.
g01055411
Explosion Hazard! Improper jumper cable connec-
tions can cause an explosion resulting in serious
injury or death. Batteries may be located in sep-
arate compartments. R efer to the Operation and
Maintenance Manual for the correct jump starting
procedure.
Refer to Operation and Maintenance Manual, “Engine
StaringwithJumpStartCables”.
Do No t Operate (10) (Winch)
Safety message (10) is located on the right side of
the machine on the vertical wall of t he winch frame.
g01055734
Do not operate or work on this equipment unless
you have read and understand the instructions
andwarningsintheOperationandMaintenance
Manual. Failure to follow the instructions or heed
the warnings could result in injury or death. Con-
tact any Caterpillar dealer for replacement manu-
als. Proper care is your responsibility.
Laser
If your machine is equipped with the AccuGrade -
Laser System, this safety message is located on
each leg of the tripod for the laser.
g01282876
Movement of the transmitter could cause unex-
p
ected blade movement. Death or serious injury
could occur. Turn off the transmitter before you
move the transmitte r or before you adjust the
transmitter.
