CAT D3K, D4K and D5K Track-Type Tractors Operation and Maintenance Manual Page 87

Operation and Maintenance Manual
SEBU8213-04 87
Maintenance Section
Lubricant Viscosities and Refill Capacities
i02516980
Capacities (Refill)
SMCS Code: 7000; 7560
Table 11
APPROXIMATE REFILL CAPACITIES
Compartment or System
Liters
US Gal Imp Gal
Engine Crankcase
11 2.9 2.4
Each Final Drive D3K 8.2 2.2 1.8
Each Final Drive D4K 9.5 2.5 2.1
Each Final Drive D5K 9.5 2.5 2.1
Hydraulic Tank 60 15.8 13.2
Hydraulic System 84 22.2 18.4
Fuel Tank 195 51.5 42.9
Radiator for the Cooling System
7.5 2.0 1.6
Cooling System
22.4 5.9 4.9
Gear Case for the Winch
4.7 1.2 1.0
i01822901
S·O·S Informatio n
SMCS Code: 7542
S·O·S Services is a highly recommended process
for Caterpillar customers to use in order to minimize
owning and operating cost. Customers provide
oil samples, coolant samples, and other machine
information. The dealer uses the data in order to
provide the customer with recommendations for
management of the equipment. In addition, S·O·S
Services can help determine the cause of an existing
product problem.
Refer to Special Publication, SEBU6250, “Caterpillar
Machine Fluid Recommendations” for detailed
information concerning S·O·S Services.
Refer to the Operation and Maintenance Manual,
“Maintenance Interval Schedule” for a specific
sampling location and a service hour maintenance
interval.
Consult your Caterpillar dealer for complete
information and assistance in establishing an S·O·S
program for your equipment.
