CAT D3K, D4K and D5K Track-Type Tractors Operation and Maintenance Manual Page 31

Operation and Maintenance Manual
SEBU8213-04 31
Product Information Section
General Information
Table 4
D5K HYSTAT TRACK-TYPE TRACTOR
Operating Weight (LGP)
(1)
9683 kg (21347 lb)
Operating Weight (XL)
(1)
9408 kg (20741 lb)
Operating W
eight (SLGP)
(2)
9800 kg (216
05 lb)
Length (LGP) (A)
(3)
4294 mm (169 inch)
Length (XL) (A) 4321 mm (170.1 inch)
Length (SLGP) (A) 4294 mm (169 inch)
Width (LGP) (B) 2410 mm (94.9 inch)
Width (XL) (B) 21 10 mm (83.0 inch)
Width (SLGP) (B) 2410 mm (94.9 inch)
Height to top of ROPS (C) 2769 mm (109 inch)
Blade width (LGP) (D) 3220 mm (126.8 inch)
Blade width (XL) (D) 2782 mm (109.5 inch)
Blade width (SLGP) (D) 3220 mm (126.8 inch)
Note: Add 235 kg (518 lb) to the operating weight for
machines with “EROPS”.
Intended Use
This Track-Type Tractor is an earthmoving
machine that is described by “ISO 6165:2001”. The
Track-Type T ractor is classified as a Tractor-dozer.
The tractor-dozer is a self-propelled crawler with
equipment such as a dozing attachment which cuts,
moves and grades material through forward motion
of the machine or a mounted attachment that is used
to exert a push or a pull force such as a ripper or
towing winch. Additional applications include pushing
scrapers during loading and pulling towed equipment
when the drawbar is used.
Application/Configuration Restrictions
•
Maximum approved Operating Weight is 13300 kg
(29321 lb).
•
Maximum drawbar pull (165 kN (37100 lb))
•
Maximum vertical drawbar load (43 kN (9650 lb))
•
The maximum fore and aft slope on this machine
in a static condition that maintains the proper
lubrication is a 100 percent grade or a 45 degree
slope.
•
The brake capacity (slope) of this machine is 45
degrees.
•
Do not use the machine in explosive environments.
Special attach
ments and operating instructions are
required for Waste Handling applications and other
Custom configurations.
