CAT D3K, D4K and D5K Track-Type Tractors Operation and Maintenance Manual Page 78

Operation and Maintenance Manual
78 SEBU8213-04
Operation Section
Transportation Information
Table 9
D3K, D4K, and D5
K Track-Type Loaders
The m achine is operated with the dozer blade, the
ROPS canopy, the backup alarm, the operator (75 kg
(165 lb)), co
olant, lubricants and the full fuel tank.
(1)
D3K XL
7795 kg
(17185 lb)
D3K LGP
8093 kg
(17842 lb)
D4K XL
8147 kg
(17961
lb)
D4K
LGP
8501
kg
(18742
lb)
D5K
XL
9408
kg
(20741
lb)
D5K
LGP
9683
kg
(21347
lb)
Radiator grill (HD)
43 kg (95 lb)
++++++
Rear guard
116kg(256lb)
++++++
ROPS cab
235kg(518lb)
++++++
ROPS cab (logging machine)
324kg(715lb)
+++++
Auxiliary drive
+31 kg
(68 lb)
+31 kg
(68 lb)
+32 kg
(71 lb)
+32 kg
(71 lb)
-12 kg
(26 lb)
-12 k g
(26 lb)
Installation AR (winch)
+91 kg
(201 lb)
+91 kg
(201 lb)
+93 kg
(205 lb)
+93 kg
(205 lb)
+47 kg
(104 lb)
+47 kg
(104 lb)
Ripper
612 kg (1350 lb)
++++++
Winch mounting
111kg(245lb)
++++++
Front counterweight
286kg(630lb)
++++++
Accugrade Installation (Attachment ready option)
16 kg (35 lb)
++++++
Hydraulic system (4 valve)
19 kg (42 lb)
++++++
Front sweep assembly
132kg(291lb)
++++++
Rear sweep assembly
56 kg (124 lb)
++++++
Screens (canopy) at the front and the door
67 kg (148 lb)
++++++
Side screen
55 kg (121 lb)
++++++
Rear screen (cab)
43 kg (95 lb)
++++++
Rear screen (canopy)
39 kg (86 lb)
++++++
Full track roller guard
+74 kg
(163 lb)
+74 kg
(163 lb)
+85 kg
(187 lb)
+85 kg
(187 lb)
+105
kg
(232 lb)
+105
kg
(232 lb)
Guide guard (center track)
+24 kg
(53 lb)
+24 kg
(53 lb)
+26 kg
(57 lb)
+26 kg
(57 lb)
+31 kg
(68 lb)
+31 kg
(68 lb)
Sound suppression (EEC)
5kg(11lb)
++++++
Other Approved Attachments or Work tools
++++++
The Total Mass of the Machine without the operator
======
(1)
The weights that are given herein describe the mac hine as the m achine is m anufactured by Caterpillar Inc.
