CAT D3K, D4K and D5K Track-Type Tractors Operation and Maintenance Manual Page 64

Operation and Maintenance Manual
64 SEBU8213-04
Operation Section
Machine Operation
Table 8
DECLARATION OF CONFORMITY
We, Quake Global, Inc (Previously Quake Wireless, Inc up to January 2001)
of 9765 Clairemont Mesa Blvd, Suite A (Previously 5575 Ruffin Road, Suite 100 up to March 2002)
San Diego
CA 92124, Usa (Previously 92123)
declare under our sole responsibility that the product
QHE2500, Q2000,Q1500, Q1400, Q1200S, Q1200SG, Q1200SH, Q1200SM and Q1200SV
to which this declaration relates, is in conformity with the following standards and / or other normative documents.
EN 301 721 V1.2.1 (June 2001)
EN 300 489-20V1.2.1 (November 2002)
EN 60950-1/A11:2004, 1st Edition
We hereby declare that all essential radio test suites have been carried out and that the above named product is in conformity
to all the essential requirements of Directive “1999/5/EC”.
The conformity assessment procedure referred to in Article 10 and detailed in Annex [IV] of Directive “1999/5/EC” has been
followed with the involvement of the following Notified Body:
BABT, Claremont House, 34 Molesey Foad, Walton-on-Thames, KT12 4RQ, UK
Identification mark: 0168 The equipment will also carry the
Class 2 Equipment identifier.
The technical documentation relevant to the above equipment will be held at:
Quake Global Inc (Previously Quake Wireless, Inc. up to January 2001)
9765 Clairemont Mesa Blvd, Suite A
Sa
n Diego, CA 92124, USA
Polina Braunstein
President
(signature of authorized person) (date)
Class 2 equipment identifier
