CAT D3K, D4K and D5K Track-Type Tractors Operation and Maintenance Manual Page 61

Operation and Maintenance Manual
SEBU8213-04 61
Operation Section
Machine Operation
Machine Speed (
Indicator)
Speed setting – The indicator displays the speed
setting durin
g machine operation.
Engine Oil Pressure
Engine oil pressure – The indicator displays the
status of the engine oil pressure during machine
operation.
Tachometer
Digital tachometer – The tachometer displays the
engine rpm during machine operation.
System Voltage
System vol
tage – System voltage displays the
status of the electrical system during machine
operation.
Service Hour Meter
Servic e
Hour Meter – This display
indicates the total operating hours of
the engine. Use the display in order to
determi
ne the service hour maintenance intervals.
Service Code
Refere
nce: The Gauge Display in the digital display
window will display the appropriate service codes
when the service codes a re activated.
Electronic Monitoring System
The electronic monitoring system has screens for t he
service mode that may indicate that a problem exists.
These units of measurement display the diagnostic
codes.
Contact your Caterpillar dealer for more information
on the service modes.
i03555467
Product Link
(If Equip ped)
SMCS Code: 7606
The Product Link PL121SR is a satellite
communication device that transmits information
regarding t
he machine to Caterpillar, Caterpillar
dealers, and Caterpillar customers. The unit contains
a Global Positioning System receiver (GPS receiver)
and a satell
ite transceiver.
The Product Link PL121SR is capable of two-way
communica
tion between the machine and a remote
user. The remote user can be a dealer or a customer.
At any time, a user can request updated information
from a mach
ine such as hours of use or the location
of the machine. Also, the system parameters for
Product Link PL121SR can be changed. Data is
transmit
ted from the machine to a satellite. Next, the
data is transmitted to a ground station. The receiving
stationtransmitsthedatatoCaterpillarInc.Thedata
can then
be sent to a Caterpillar dealer and to the
customer.
Data Bro adcasts
Machine
data about the machine's condition and
operation is being transmitted by Product Link to
Caterpillar and/or Caterpillar dealers in order to
better
serve the customer and to improve Caterpillar
products and services. The information that is
transmitted may include the following data: machine
seria
l number, location of the machine, fault codes,
emissions data, fuel usage, service meter hours,
version numbers for software and hardware, and
insta
lled attachments.
Caterpillar and/or Caterpillar dealers may use this
info
rmation for various purposes: providing services
to the customer and/or the machine, checking or
maintaining Product Link equipment, monitoring the
mach
ine's health or performance, helping to maintain
the machine, improving the machine's efficiency,
evaluating or improving Caterpillar products and
ser
vices, complying with legal requirements and
valid court orders, performing market research, and
offering the customer new products and services.
Caterpillar may share some or all of the collected
information with Caterpillar affiliated companies,
de
alers, and authorized representatives. Caterpillar
will not sell or rent collected information to any other
third party and will exercise reasonable efforts to
ke
ep the information secure. Caterpillar recognizes
and respects customer privacy. For more information,
please contact your local Caterpillar dealer.
