CAT D3K, D4K and D5K Track-Type Tractors Operation and Maintenance Manual Page 89

Operation and Maintenance Manual
SEBU8213-04 89
Maintenance Section
Maintenance Interval Schedule
i03653330
Maintenance Interval Schedule
SMCS Code: 7000
Ensure that al
l safety information, warnings and
instructions are read and understood before any
operation or any maintenance procedures are
performed.
The user is responsible for the performance of
maintenanc
e, including all adjustments, the use of
proper lubricants, fluids, fi lters, and the replacement
of components due to normal wear and aging. Failure
to adhere t
o proper maintenance intervals and
procedures may result in diminished performance of
the product and/or accelerated wear of components.
Use mileage, fuel consumption, service hours, or
calendar time, WHICH EVER OCCURS FIRST,
in order t
o determine the maintenance intervals.
Products that operate in severe operating conditions
may require more frequent maintenance.
Note: Before each consecutive interval is performed,
all maintenance from the previous interval must be
perform
ed.
Note: If Cat HYDO Advanced 10 hydraulic oil is
used, th
e hydraulic oil change interval will change.
The normal interval of 2000 hours is extended to
3000 hours. S·O·S services may extend the oil
change
even longer. Consult your Caterpillar dealer
for details.
When Required
Battery - Recycle ........ .......................................... 91
Battery or Battery Cable - Inspect/ Replace .......... 92
Circu
it Breakers - Reset ........................................ 96
Condenser (Refrigerant) - Clean .......................... 97
Cutting Edges and End Bits - Inspect/Replace ... 103
Engi
ne Air Filter Primary Element - Clean/
Replace ............................................................. 103
Engine Air Filter Secondary Element - Replace .. 105
Engi
ne Air Precleaner - Clean ............................ 106
Ether Starting Aid Cylinder - Replace ................. 109
Free Spool Drag - Adjust ..................................... 111
Fue
l System - Prime ............................................ 113
Fuel System Water Separator - Drain .................. 115
Fuel Tank Cap - Clean ......................................... 118
Fus
es - Replace ................................................... 119
Oil Filter - Inspect ................................................ 126
Radiator Core - Clean ......................................... 126
Ra
diator Pressure Cap - Clean/Replace ............ 127
Ripper - Inspect/Replace .................................... 128
Winch Cable - Replace ....................................... 133
Wi
ndow Washer Reservoir - Fill .......................... 135
Window Wipers - Inspect/Replace ...................... 136
Windows - Clean ................................................. 136
Every 10 Servic
eHoursorDaily
Backup Alarm - Test .............................................. 91
Brakes, Indic
ators and Gauges - Test ................... 94
Bulldozer Power Angling Tilt Hinge Pins -
Lubricate ............................................................. 95
Cab Filter (Fr
esh Air) - Clean/Inspect/Replace ..... 96
Cooling System Coolant Level - Check .............. 100
Engine Oil Level - Check .................................... 107
Hydraulic Sy
stem Oil Level - Check ................... 124
Seat Belt - Inspect .............................................. 129
Winch Cable - Inspect ......................................... 132
Winch Fairl
ead Rollers - Lubricate ...................... 135
Every 50 Service Hours or Weekly
Cab Filter
(Recirculation) - Clean/Inspect/
Replace ............................................................... 96
Front Idler Position - Check/Adjust ...................... 111
Ripper Lin
kage and Cylinder Bearings -
Lubricate ........................................................... 127
Track - Check/Adjust ........................................... 130
Track Pin
s - Inspect ............................................ 131
Every 250 Service Hours or Monthly
Belt - In
spect/Replace ........................................... 93
Engine Oil Sample - Obtain ................................ 108
Final Drive Oil Level - Check ............................... 110
Fuel Tan
k Water and Sediment - Drain ................ 118
Track Roller Frame - Inspect .............................. 132
Winch Oil Level - Check ..................................... 134
Initia
l 500 Hours (for New Systems, Refilled
System
s, and Converted Systems)
Cooling System Coolant Sample (Level 2) -
Obtai
n ............................................................... 101
Every500ServiceHours
Cooli
ng System Coolant Sample (Level 1) -
Obtain ............................................................... 100
Engine Air Precleaner - Clean ............................ 106
Fina
l Drive Oil Sample - Obtain ........................... 111
Hydraulic System Oil Sample - Obtain ............... 125
Winch Oil Sample - Obtain ................................. 134
Ever
y 500 Service Hours or 3 Months
Engine Oil and Filter - Change ........................... 108
Fue
l System Secondary Filter - Replace ............. 114
Fuel System Water Separator - Replace ............. 116
Every 500 Service Hours or 1 Year
Trunnion - Adjust ................................................. 132
Winch Drum Bearing - Lubricate ......................... 135
Ev
ery 1000 Service Hours or 6 Months
Battery - Inspect .................................................... 91
E
ngine Valve Lash - Check ................................. 109
Previous page
Next page
