Caterpillar Engine Tools Cat Overhaul 3512 Page 147

Operation and Maintenance Manual
2592062
3-147
Engine Tools
Cylinder Head, Valves and Cam Followers
Sleeve Replacement Tools (Continued)
Model: 3114, 3116 and 3126 Engines
Warranty: Six Months
Item Description
18 Bolt
Included (Not shown)
NEEG2748 Decal
NEHS0675 Tool Operating Manual,
“Usingthe143-2099SleeveRe-
placement Tool Group on 3114,
3116 and 3126 Engines”
143-2099 Sleeve Replacement Tool Group
Item Part Number Description Size
1 125-7060 Driver --
3 4C-8714 Guide Bushing
(large)
--
4 4C-8715 Guide Bushing
(small)
--
6 125-7059 ReactionSleeve
(HEUI)
--
7 9U-5671 ReceiverSleeve
Adapter
1
--
8 4C-5572 Plate (for reac-
tionsleeve)
--
9 121-2920 Roller Expander --
10
2
9U-6101 Reamer Group --
11 142-8278 Swage Tool --
12 142-8279 SleevePuller --
13 142-8280 SleeveStud --
14 142-8281 Plate --
15 143-8612 Driver --
17 7D-1649 Hard Washer --
19 6V-3821 Hex Bolt M8 x 1.25, 110 mm
(4.3 in) long
20 4C-5553 SleeveCleaning
Brush (tapered)
--
143-2099 Sleeve Replacement Tool Group
Item Part Number Description Size
21 126-3297 Large Bore Brush --
22 4C-5570 Small Bore Brush --
23 9U-6859 Pick Set --
24 214-6625 Socket 11 mm, 3/8 in
squaredrive,six
point
25 213-3530 Socket 1 1/8 in
26 2J-3506 Nut 3/4 - 10 thd
27 1U-8826 Thrust Bearing --
28 2S-0115 Washer --
29 1B-4430 Jam Nut 1/2 - 20
Item 2 - Reamer Assembly
3
2 4C-8713 Reamer Shank --
2 4C-5502 Set Screw --
Item 5 - Swage Assembly
5 4C-5573 Swage(sleeve) --
5 4C-5548 Stud 3/4 - 10 thd x 5
1/2 in
Not shown
1 6V-7145 Case --
-- 125-0684 Foam Insert --
1
9U-5671Sleeve36.0mm(1.42in)98.0mm(3.86in)Openend
2
Includes: 9U-6102 Reamer, 9U-6103 Collar, 9U-6104 Compression Spring, and 9U-6105 Guide Bushing
3
Includes: Reamer Head
