Caterpillar Engine Tools Cat Overhaul 3512 Page 282

Operation and Maintenance Manual
2596823
3-282
Engine Tools
Fuel System Repair and Adjust
5P-4203 Sleeve Metering Field Service Tool Group (Continued)
Model: Cat
®
Engines
Warranty: Six Months
Item
Part
Number Description Size Qty.
1 3P-1549 Block -- --
1 2P-8306 Box Assembly -- --
2 5P-0301 Driver -- --
3 1P-0529 Handle -- --
4 4B-4280 Washer -- 2
5 1D-4538 Bolt -- --
6 1D-4533 Bolt -- --
7 3K-4910 Screw -- --
8 0S-1603 Bolt -- --
10 8B-8817 Plug (Not
shown)
-- --
10 8T-0853 Gauge, 0 - 400
kPa(0 - 60 psi)
-- --
11 5P-0319 Driver -- --
12 5P-0318 Driver -- --
13 1P-0463 Plate 1.000 in Diameter --
14 6L-5551 Bolt 2 1/4 in long --
15 4L-7124 Bolt - Hex
Socket Head
1
1 1/4 in long --
16 4B-4276 Flat Washer -- 4
17 6J-3958 Coupling -- --
17 3B-7734 Adapter STR 76.2 long (1/8 in NPT x
3 in)
--
17 3J-7354 Seal - O-ring
- STOR for
8C-3446 (not
pictured)
-- 2
17
2
5D-9231 Connector -- 2
18 3P-
2210
3
Socket -- --
19
4 5
5P-6602 Adapter -- --
20
4
5P-4205 Wrench
6
-- --
Item
Part
Number Description Size Qty.
21 3P-1544 Pin -- --
22 4H-0553 Fitting -- --
23 5P-0299 Pin 19.2831 mm (0.7592 in) --
24 5P-0298 Pin 17.8587 mm (0.7028 in) --
25
4
5P-4209 Gauge -- --
26 3J-6956 Spring -- --
27 8S-7271 Setscrew -- --
28 8S-2243 Wrench -- --
29 3P-1565 Collet Clamp -- --
31 5P-0302 Bar (Injector
Removal)
-- --
32 6V-0029 Roll Pin Depth
Gauge Tool
2
-- --
33
2
6V-3071 Seal Guide -- --
-- 5P-4203 SleeveMe-
tering Field
ServiceTool
Group
-- --
3P-1567 Indicator, Includes:
30 3P-1567 Indicator -- --
30
4
5P-6531 Point 57.2 mm (2.25 in) --
30
4
5P-4228 Spring -- --
The following parts which, were in the discontinued 3P-1550
Tool Group, should be retained in case of the possible need
for dynamic checking of sleeve shaft movement
7
-- 3K-6896 Gasket -- --
-- 0S-1616 Bolt -- --
-- 7B-2742 Bolt -- --
1
Partof1P-0520DriverGroup
2
Not included in early 5P-4203 Groups
3
Special socket
4
Toolswhichmustbeprocuredtoconvertthediscontinued3P-1550ToolGrouptothe5P-4203ToolGroup.The3P-1567Indicatorsfromdiscon-
tinued3P-1550ToolGroupsmusthavethe5P-4228Springand5P-6531ContactPointinstalled.Some3P-1567Indicatorshad5P-4809Points,50.8
(2.0 in) long.
5
NOTE: The discontinued 5P-4226 Adapter was replaced by the 5P-6602 Adapter, which is required for 3208 Engines with EGR systems.
6
Warranty: Six Months
7
Also retain: Basket
