3-48

Engine Tools

Crankshaft, Main Bearings and Flywheel

5P-8718 BrakeSaver Rotor Support

Model: 3406, 3406B, 3408, 3408B

Warranty: Six Months

• Usedtopreventdamagetoseals

duringBrakeSaverremovaland

installation on 3400 Series Engines

• Attached to engine with four 0S-

1594 Bolts

• Replaces 9N-0046 design changes

Part Number Description

5P-8718 BrakeSaverRotor

Support

FT1895 Plug

FT1896 Bolt

Model: Cat

EngineswithBrakeSavers

Warranty: None

• Makereplacementofdiaphragminbrakesavercontrolvalveeasier

• Holdspoolvalveinplacewhilereplacingdiaphragm

• Reduce loss of oil

8F-4423 Flywheel Lifter

Model: Cat

Engines

Warranty: Six Months

• Usedforywheelremovaland

installation

• Twolifterscanbeusedforremoval

and installation of some crankshafts

• Maximum lifting capacity: 454 kg

(1000 lb)

Part Number Description

8F-4423 Lifter - Flywheel
