Caterpillar Engine Tools Cat Overhaul 3512 Page 71

Operation and Maintenance Manual
2588819
2588833
2588848
3-71
Engine Tools
Crankshaft, Main Bearings and Flywheel
FT1206 Pusher Plate
Model:16GMotorGradersand623BElevatingScrapers
Warranty: None
• Usedforenginein-chassissealandwearsleeveinstallation
FT0884 Dimensions to Modify 1P-2321 Puller Assembly
Model: Cat
®
Engines
Warranty: None
• Usedtoremoveoilthroweron
engines with ring-type crankshaft
rear seal
Part Number Description
1P-2321 Jaw Puller Assembly
FT0108 Driver Handle
Model: D10, D10N, D8K, D9H, D9L, 651E, 657E
Warranty: None
• UsedwithFT0101,FT0102,FT0106,FT0807,andFT0885DriverBodies
