3-290

Engine Tools

Fuel System Repair and Adjust

180-0186 Removal Tool

Model: 3126B HEUI Engine

Warranty: Six Months

• Used to quickly and easily separate

175-3236 High-Pressure Hose from

tting

• Insertbevelededgebetweentting

collarandhosecollar;hoseshould

releasefromtting

Part Number Description

180-0186 RemovalTool

250-6092 Removal Tool

Essential Tool

Model: C15 and 3456 Engines

Warranty: Six Months

• Used to quickly and easily separate

ahosefroma#8tting

• Used on C15 Engine turbocharger

supply line and 3456 Engine crank-

gear

• Insertedgeoftoolbetweentting

and hose collar to release hose

fromtting

• Helpspreventhosedamage—

angled end of tool allows hose to be

pushedoffoftting

• Otherhosereleasetoolsalsoavail-

able: #6 180-0186 and #10 192-5092

Part Number Description

250-6092 RemovalTool

Injector Installation and Removal Tooling

Essential Tool

Model: 3126B, C7, C9 Engines

Warranty: Six Months

• Used to push injector into bore (attaches to rocker shaft bolt)

• Usedwith1/2inchdriveratchettoapplyforcetoraiseorlowerinjector

• Leveractionprovidesfastandeasyinstallation

• Eliminates injector damage which can occur when using other installation

methods

• Order parts separately

References

SENR9664, C9 Marine Engine

RENR9218, C7 Engine for Cat Built Machines

RENR9579, C9 Engine For Cat Built Machines

RENR7458, C7 On Highway Engine

(Continued)
