Caterpillar Engine Tools Cat Overhaul 3512 Page 39

Operation and Maintenance Manual
2587701
2587721
3-39
Engine Tools
Cooling System
359-4915 Fan Drive Installer, 359-4916 Fan Drive Installer
Essential Tool
Model: D6R, D6T Track-Type Tractors, 937D Track-Type Loader
Warranty: Six Months
• Usedtoinstallwearsleeveson336-
7696and350-5637FanDrives
• Providesawaytoinstallwear
sleeveswithoutdamagetosealsor
fandrive
• Made from hardened steel and
blackoxidecoatedforlongservice
life
Reference
RENR8175, D6R Series III and D6T Track-
Type Tractors, Engine Supplement, Disas-
sembly and Assembly
Item Part Number Description
1 359-4915 FanDrive
Installer
2 359-4916 FanDrive
Installer
Assembly Tooling for MESABI Radiator
Model: 793, 797 Off-Highway Truck
Warranty: Six Months
• Used to assemble MESABI Radiator
• Varioustoolsandlubricatingoilprovidemeanstocorrectlyassembleradiatorcomponents,includingseals
• Specialhandtoolsdesignedtohelppreventdamagetotheradiatorduringassembly
References
KENR8578, 793F Off-Highway Truck, Engine Supplement, Disassembly and Assembly
KENR8384, 797F Off-Highway Truck, Engine Supplement, Disassembly and Assembly
Part Number Description
FT3163 As Fixture
FT3164 As Fixture
FT3165 Bracket
Part Number Description
342-2334 Support Tool
342-2335 Cleaning Brush
342-2346 Lubrication Brush
342-2348 Lubrication Brush
342-2349 Lubricating Oil
4Q-5144 Install Tool
4Q-5222 Breaker Tool
