Caterpillar Engine Tools Cat Overhaul 3512 Page 218

Operation and Maintenance Manual
2645855
2645939
2646044
3-218
Engine Tools
Fuel System Test Tools
Additional Required Hardware for 135-2916 Mounting Drive Group
Warranty: Six Months
The following list of hardware is required, but not included as part of the 135-2916
MountingDriveGroup(notserviced).Thistoolingcanbepurchasedasneeded.
Drive Adapters for 4C-8723 Jaw Assembly
Item Part No. Description Where Used Qty.
1 6V-6097 CamshaftDriveAdapter
Assembly
camshaftdrive(10de-
gree helix with 50 teeth)
--
2 1U-8700 CamshaftDriveAdapter
Assembly
camshaftdrive(15de-
gree helix with 50 teeth)
--
3 4C-8249 CamshaftDriveAdapter
Assembly
camshaftdrive(15.615
degree helix with 52
teeth)
--
4 6V-6099 CamshaftDriveShieldAs-
sembly
1
-- 1
5 4L-7124 Bolt - Hex Socket Head
2
-- 4
6 0L-1143 Bolt bolt,driveadapterto
injection pump cam
3
1
Some later 6V-6101 Plate Assemblies do not include shield.
2
Partof1P-0520DriverGroup
Drive Adapters for Discontinued 4C-8192 Heavy-Duty Coupling
Warranty: Six Months
Item Description
4 Pusher Bolt
Item Part Number Description Quantity
1 4C-8193 CamshaftDriveAdapterAssembly --
2 4C-8194 CamshaftDriveAdapterAssembly --
3 126-1826 CamshaftDriveShieldAssembly --
5 0L-1143 Bolt 3
6 8H-0707 Bolt 4
Adapter Part Numbers and Usage
Usage 4C-8723 Jaw Assembly
4C-8192 Heavy-Duty Coupling
Group
1
3406B PEEC Engine - 8TC, 3406B Truck Engine - 4MG3600-UP, 15
degree Helix with 50 teeth
1U-8700 4C-8193
2 3
3406B PEEC Engine - 3ZJ, 3406B Truck Engine - 4MG3600-UP,
15.615 degree Helix with 52 teeth
4C-8249 4C-8194
2 3
3406 Truck Engine - 7FB and 4MG3600-DOWN, 10 degree Helix
with 50 teeth
6V-6097 6V-6097
4
1
Discontinued
2
Requires 126-1826 Oil Shield Assembly on 6V-6101 Plate Assembly.
3
Requires4C-8189DriveTube.
4
Attachthe4C-8723JawAssemblyontothediscontinued4C-8192Heavy-DutyCouplingGroup.
