Caterpillar Engine Tools Cat Overhaul 3512 Page 185

Operation and Maintenance Manual

Page of 420

/ 420

2645131

3-185

Engine Tools

Engine Test Tools

Tractor-Scrapers

Model Serial Number Adapter

DW15 45C, 59C, 70C, 75D, 76D FT0725

DW20 21C, 57C, 67C, 87E, 88E FT0725

DW21 58C, 69C, 85E, 86E FT0725

613 71M FT0730-4

613B 38W FT0730-4

619B 89E, 90E FT0725

619C 61F¹, 62F FT0718-1

621 23H FT0723-1

621B 45P, 35V FT1177-3

623 52U FT0723-1

623B 46P FT1177-3

627 50K, 54K, 68M, 69M FT0719-2

627B 14S FT0719-2

630A 52F¹ FT0718-1

630B 14G1-438¹, 14G442¹, 14G-1443¹ FT0718-1 or FT0775-2

630B 14G439, 14G440, 14G441, 14G444 Up FT0718-1 or FT0775-2

631A 51F¹ FT0718-1 or FT0775-2

631B 13G1-3062¹ FT0718-1 or FT0775-2

631B 13G-3063 FT0775-2

631C 67M FT0775-2

631D 24W FT1177-3

632 14G FT0718-1

63 44J FT0775-2
