CAT 315 Part Manual Page 1023

Part Manual
OPERATOR STATION
259-7198 LINES
GP-HEATER
S/N: CJN1 -UP
PART OF 259-719
7 HEATER AR-CAB
AN ATTACHMENT
SMCS-1812, 7304 i02910649
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 4I-4580 1 FITTING
21 7I-0375 1 ELBOW
31 7K-1181 1 STRAP-CABLE
41 122-9605 2TUBE
–OR–
1 6P-8855 2TUBE
51 155-7024 2 SPACER-SPECIAL
61 173-8073 1 SPACER (11X25X20-MM THK)
71 235-9014 8 CLAMP-HOSE
–OR–
1 5D-1026 8 CLAMP-HOSE
81 235-9015 2HOSE
91 266-6310 1 BRACKET AS
10 1 283-2893 1 RECEPTACLE AS
1 8T-8737 2 PLUG-SEAL
1 243-4505 1 RECEPTACLE AS-CONNECTOR (2-PIN)
11 1 293-1230 1 SUPPORT AS
12 1 095-0913 1CLIP
13 1 132-5789 1CLIP
14 1 4S-1962 6CLIP
15 1 6D-1641 3CLIP
16 1 7Y-8168 2 GROMMET
M17 1 8T-3647 1 BOLT (M8X1.25X80-MM)
18 1 8T-4121 14 WASHER-HARD (11X21X
2.5-MM THK)
M19 1 8T-4137 9 BOLT (M10X1.5X20-MM)
M20 1 8T-4172 3 BOLT (M10X1.5X80-MM)
M21 1 8T-4191 1 BOLT (M10X1.5X16-MM
)
M22 1 8T-4196 1 BOLT (M10X1.5X35-MM)
23 1 8T-4223 2 WASHER-HARD (13.5X25.5X3-MM THK)
24 1 8T-4224 1 WASHER-HARD (8.8X16
X2-MM THK)
M25 1 8T-4910 2 BOLT (M12X1.75X60-MM)
E26 1 5P-0767 HOSE (350-CM)
E26A 1 5P-0767 HOSE (250-CM)
27 1 305-0441 2 BAND-MARKER (HS)
28 1 305-0442 2 BAND-MARKER (HR)
E-ORDER BY THE CENTIMETE
R
M-METRIC PART
SEBP4861-02 1of2 OPER ATOR STATION 993
