CAT 315 Part Manual Page 285

Part Manual

Page of 1181

/ 1181

ELECTRICAL AND STARTING SYSTEM

259-5171 WIRIN

G GP-M EDIU M PRESSURE

S/N: CJN1 -UP

PART OF 259-756

5, 270-5954 CONTROL AR-AUXILIARY

AN ATTACHMENT

SMCS-1408 i02749973

NOTE

REF

GRAPHIC

REF PART NUM BER QTY

PART NAM E

123456(PRODUCT LEVEL

)

SEE

PAGE

11 3S-2093 5 STRAP-CABLE

21 7K-1181 8 STRAP-CABLE

31 116-0118 2CLIP

41 267-7705 1 HARNESS AS-VALVE

1 3S-2093 2 STRAP-CABLE

E1125-7874 TUBE-HEAT SHRIN

K (5.72-MM DIA) (5-CM)

1 155-2270 2 KIT-CONNECTING PLUG (2-PIN)

(EACH INCLUDES PLUG AS, WEDGE & INTERFACE

SEAL)

1 243-4506 1 RECEPTACLE AS-CO

NNECTOR (3-PIN)

51 132-5789 2CLIP

61 6G-2263 2 SPACER (10.5X19X28.5-MM THK)

M7 1 7X-2621 1 BOLT (M10X1.5X12

-MM)

81 8T-4121 3 WASHER-HARD (11X21X2.5-MM THK)

M9 1 8T-4182 1 BOLT (M10X1.5X45-MM)

M10 1 8T-4186 1 BOLT (M10X1.5X40

-MM)

E-ORDER BY THE CENTIMETER

M-METRIC PART

GRAPHIC #1 <END> g01379761

SEBP4861-02

1of1 ELECTRICAL AND STARTING SYSTEM 255
