CAT 315 Part Manual Page 419

Part Manual
HYDRAULIC SYSTEM
255-5843 CONTR
OL AR-A UXIL IARY
–
JOYSTICK WITH S
LIDE C ONTROL
S/N: CJN1 -UP
AN ATTACHMENT
SMCS-5051 i02431300
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
Y 259-7598 1 CONTROL & MTG GP-JOYSTICK (WITH SLIDE CONTROL) 898
Y 259-5295 1 FASTENER GP-WIRING HARNESS (JOYSTICK) 158
Y 247-7410 1 FILM GP (OPERAT
OR CONTROLS, NOTICE)
1079
Y-SEPARATE ILLUSTRATION
<END>
255-5844 CONTROL A R-AUXILIARY –
JOYSTICK, 3-BUTTON, TRIG GER SW
S/N: CJN1 -UP
AN ATTACHMENT
SMCS-5051 i02430669
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 259-7599 1 CONTROL & MTG GP-JOYSTICK 900
Y 259-5295 1 FASTENER GP-WIRING HARNESS (JOYSTICK) 158
Y 247-7411 1 FILM GP (OPERATOR CONTROLS, NOTICE) 1081
Y-SEPARATE ILLUSTRATION
<END>
259-7557 CONTROL AR-AUXILIARY–COMBINED FUNCTION
S/N: CJN1 -UP
AN ATTACHMENT
SMCS-5051 i02784096
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 260-8226 1 LINES GP-FRONT 505
Y 260-7891 1 LINES GP-PILOT (PUMP CONTROL, SHUTTLE VALVE) 547
Y 302-3258 1 LINES GP-PILOT (CONTROL VALVE, PUMP) 597
Y 278-6438 1 LINES GP-PUMP 617
Y 285-1738 1 VALVE & MTG GP-CONTROL 673
Y 259-5169 1 WIRING GP-AUXILIARY CONTROL 214
Y 259-5165 1 WIRING GP-CAB (WORK TOOL PRIORITY) 222
Y-SEPARATE ILLUSTRATION
<END>
SEBP4861-02 HYDRAULIC SYS TEM 389
