CAT 315 Part Manual Page 15

Part Manual
MAINTENANCE PARTS
DESCRIPTION
PART
NUMBER QTY WHERE USED PAGE
ELECTRICAL AND STARTING SYSTEM
BATTERY
(12-VOLT, MAINTENANCE FREE, WET)
3T-5760 2 BATTERY & WIRING GP 127
2 BATTERY & WIRING GP 133
9X-3404 2 BATTERY GP 139
CIRCUIT BREAKER AS (60-AMPERE)
(ALTERNATOR)
171-2208 1 PANEL GP-CIRCUIT BREAKER 181
CIRCUIT BREAKER AS (80-AMPERE)
(MAIN)
171-2210 1 PANEL GP-CIRCUIT BREAKER 181
FUSE (10-AMPERE) 113-8490 20 WIRING GP -CAB 216
FUSE (15-AMPERE) 113-8491 5 WIRING GP-CAB 216
FUSE (15-AMPERE)
(ACCU GRADE, SOLENOID RESISTOR)
113-8491 1 WIRING GP-CAB 225
FUSE (20-AMPERE) 113-8492 3 WIRING GP-CAB 216
FUSE (25-AMPERE) 113-8493 3 WIRING GP-CAB 216
FUSE (30-AMPERE) 124-3548 2 WIRING GP-CAB 216
FUSE (5-AMPERE) 141-2759 7 WIRING GP-CAB 216
KEY (BATTERY DISCONNECT) 8H-5306 1 SWITCH GP-DISCONNECT 200
KEY AS-ELECTRONIC (SECURITY) 206-5162 2 INSTALLATION GP-SECURITY 161
LAMP AS (24-VOLT, 3-WATT) 170-9324 1 PANEL GP-SWITCH 183
1 PANEL GP-SWITCH 185
LAMP-HALOGEN (24-VOLT, 65-WATT) 9X-3463 1 LAMP GP-FLOOD 164
1 LAMP GP-FLOOD 165
1 LAMP GP-FLOOD 166
1 LIGHTING GP-FLOOD 170
LAMP-HALOGEN (24-VOLT, 65-WATT)
(CANOPY)
9X-3463 1 LIGHTING GP-FLOOD 173
FUEL SYSTEM
CAP GP-FUEL FILLER
(EXTREME SERVICE, LOCKABLE)
164-4858 1 TANK GP-FUEL 104
1 TANK GP-FUEL 106
1 TANK GP-FUEL 108
1 TANK GP-FUEL 110
1 TANK GP-FUEL 113
1 TANK GP-FUEL 115
1 TANK GP-FUEL 118
1 TANK GP-FUEL 120
FILTER (ADVANCED EFFICIENCY)
(FUEL)
1R-0751 2 FILTER GP-FUEL 81
FILTER AS-WATER SEP & FUEL
(PRIMARY)
326-1644 1 FILTER GP-WATER SEP & FUEL 84
GASKET (FUEL PRIMING PUMP) 294-1820 1 FILTER GP-FUEL 81
KEY 5P-8500 1 TANK&MTGGP-FUEL 102
STRAINER AS-FUEL (FLOAT GAUGE) 303-9933 1 TANK GP-FUEL 104
1 TANK GP-FUEL 106
1 TANK GP-FUEL 108
1 TANK GP-FUEL 110
1 TANK GP-FUEL 113
1 TANK GP-FUEL 115
1 TANK GP-FUEL 118
1 TANK GP-FUEL 120
SEBP4861-02 MAINTENANCE PARTS A11
