CAT 315 Part Manual Page 620

Part Manual
HYDRAULIC SYSTEM
302-3195 LINES
GP-PILOT
–MAIN CONTROL VALV E, MANIFOLD
S/N: CJN1 -UP
PART OF 259-754
7 HYDRAULIC AR
SMCS-5057, 5059 i03148224
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
I1 2 4I-0797 1 HOSE AS
I2 2 4I-0800 1 HOSE AS
I3 3 4I-0821 2 HOSE AS
I4 2 4I-1760 1 HOSE AS
I5 2 4I-1783 1 HOSE AS
I6 2 4I-5795 1 HOSE AS
I7 1 4I-6248 1 HOSE AS
I8 1 4I-6391 1 HOSE AS
91,2 4I-9521 6 BAND-MARKER (RED, L1)
10 1,2 4I-9522 4 BAND-MARKER (YELLOW, L2)
11 1,2 4I-9523 12 BAND-MARKER (BLUE, L3)
12 1,2 4I-9524 4 BAND-MARKER (BROWN, L4)
13 2 4I-9525 2 BAND-MARKER (ORANGE, R1)
14 1,2,3 4I-9527 6 BAND-MARKER (GREEN, R3)
15 2,3 4I-9528 4 BAND-MARKER (PURPLE, R4)
I16 2 325-8876 1 HOSE AS
17 1,2,3 7K-1181 15 STRAP-CABLE
18 3 224-1914 1 HOSE AS
I19 1 7Y-8379 1 HOSE AS
I20 2 087-4411 1 HOSE AS
I21 2 087-5771 1 HOSE AS
I22 2 087-5772 1 HOSE AS
I23 1 087-5773 1 HOSE AS
I24 2 087-5783 1 HOSE AS
I25 3 087-6582 1 HOSE AS
I26 3 087-6585 1 HOSE AS
I27 2 108-7402 1 HOSE AS
Y28 3 123-2430 1 VALVE GP-SHUTTLE 729
29 1 133-5813 2 BAND-MARKER (GRAY, P)
30 4 164-5628 1 CONNECTOR AS
4 3J-1907 1 SEAL-O-RING
4 6V-8397 1 SEAL-O-RING
4 107-6631 1 CONNECTOR-FILTER
Y31 2 164-6981 1 ACCUMULATOR GP-HYDRAULIC (CHARGED) 386
32 3 309-5769 1 SWITCH AS-PRESSURE (PILOT, BOOM UP)
3 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
3 9X-3401 2 PIN-CONNECTOR (16-GA TO 18-GA)
–OR–
3 126-1767 2 PIN-CONNECTOR (14-GA)
33 3 168-1968 1 TEE AS
3 3J-1907 1 SEAL-O-RING
3 6V-8397 1 SEAL-O-RING
3 126-6872 1 TEE
34 3 176-4791 1 BLOCK
I35 3 199-1914 1 HOSE AS
I36 1 199-1965 1 HOSE AS
I37 2 207-6418 1 HOSE AS
Y38 2 215-5037 1 MANIFOLD GP-CONTROL (PILOT OIL SUPPLY) 635
Y39 3 238-0751 1 VALVE GP-SOLENOID & PRESS REDC
(BOOM LOWERING CONTROL)
747
40 3 317-4751 1 HOSE AS
E37I-7439 GUARD (59-CM)
41 2 269-9553 1 PLATE
42 2 275-1442 2 CLIP (TAB)
43 2 275-1443 2 CLIP (SLOT)
590 HYDRAULIC SYSTEM 1of7 SEBP 4861-02
