CAT 315 Part Manual Page 629

Part Manual
HYDRAULIC SYSTEM
302-3258 LINES GP-PILOT (contd. ) i02866151
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
65 1,2 148-8433 2TEEAS
(EACH INCLUDES)
1,2 6V-8397 2 SEAL-O-RING
1,2 6V-9836 1 TEE-SWIVEL
66 2,3 148-8435 2TEEAS
(EACH INCLUDES)
2,3 3J-1907 1 SEAL-O-RING
2,3 6V-8397 2 SEAL-O-RING
2,3 6V-8781 1 TEE-FACE SEAL
67 1,2,3 150-3036 7 ELBOW AS
(EACH INCLUDES)
1,2, 3 3J-1907 1 SEAL-O-RING
1,2, 3 6V-8397 1 SEAL-O-RING
1,2, 3 8T-1905 1 ELBOW
68 3 153-6248 1 ADAPTER AS
3 6V-8397 1 SEAL-O-RING
3 8T-6663 1 ADAPTER-PORT
69 2 153-6249 1 CONNECTOR AS
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 8T-8887 1 CONNECTOR
70 2 164-5549 1 COUPLING AS
2 3J-1907 1 SEAL-O-RING
2 4I-6287 1 COUPLING
71 2,3 164-5567 6 COUPLER AS-QUICK DISC
ONNECT
(EACH INCLUDES)
2,3 3J-1907 1 SEAL-O-RING
2,3 6V-3965 1 FITTING (QUICK DISCONN
ECT)
M72 2 5C-9553 2 BOLT (M6X1X16-MM)
73 3 5P-2369 1CLIP
74 3 6K-8178 1CLIP
75 2,3 6V-0852 6 CAP-DUST
76 2 6V-8397 2 SEAL-O-RING
77 2,3 8T-4121 16 WASHER-HARD (11X21X2.
5-MM THK)
M78 3 8T-4133 2 NUT (M10X1.5-THD)
M792,3 8T-4136 12 BOLT (M10X1.5X25-MM)
M802,3 8T-4137 4 BOLT (M10X1.5X20-MM)
M81 2 8T-4177 4 BOLT (M8X1.25X90-MM)
M82 3 8T-4192 2 BOLT (M12X1.75X25-MM)
M83 2 8T-4194 3 BOLT (M12X1.75X50-MM)
84 2,3 8T-4223 5 WASHER-HARD (13.5X25.5X3-MM THK)
85 2,3 8T-4224 6 WASHER-HARD (8.8X16X2-MM THK)
M86 2 8T-6870 4 BOLT (M8X1.25X70-MM)
M87 3 8T-7547 2 BOLT (M8X1.25X30-MM)
88 2 9M-8406 1CLIP
89 2 9X-8256 2 WASHER (6.6X12X2-MM THK)
C-CHANGE FROM PREVIOUS TYPE
E-ORDER BY THE CENTIMETER
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
Y-SEPARATE ILLUSTRATION
SEBP4861-02 3of6 HYDRAULIC SYSTEM 599
