CAT 315 Part Manual Page 900

Part Manual
OPERATOR STATION
235-8908 CAB GP
–INTERIOR
S/N: CJN1 -UP
PART OF 229-909
7, 229-9099, 229-9101 CAB G P
AN ATTACHMENT
SMCS-7301, 7325 i03087701
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 8Y-6352 1 LOUVER AS
21 156-6656 1 RAIL
31 156-6657 1 RAIL
41 164-0646 1 CUP
51 164-0655 1 PANEL-SWITCH (OPERATOR CONSOLE)
61 164-8474 2 LOUVER AS-VENT
71 170-9724 5 CLIP
81 171-7420 6 CLIP
91 176-1946 1 PLATE
10 1 176-1947 1 PLATE
11 1 176-1972 1 COVER
12 1 185-8214 1 BRACKET AS
13 1 189-2678 3 SPACER
14 1 234-6468 1 COVER AS
15 1 234-6470 1 COVER-MONITOR
16 1 234-6471 1 COVER-DUCT
17 1 234-6472 1 COVER
18 1 234-6473 1 COVER-FRONT (UPPE
R, RH)
19 1 234-6474 1 COVER (UPPER, RH)
20 1 305-0330 1 COVER
21 1 234-6476 1 DUCT
22 1 234-6477 1 BRACKET AS
23 1 305-0333 1 BRACKET
24 1 234-6480 1 BRACKET AS
25 1 234-6483 1 BRACKET AS
26 1 234-6485 1 BRACKET AS
27 1 234-6490 1 CUP
28 1 234-6491 1 COVER
29 1 234-6497 1 COVER
30 1 234-6498 3 RIVET
31 1 234-6521 1 COVER
32 1 234-6547 1 COVER
33 1 234-6548 1 COVER
34 1 234-6549 1 COVER
35 1 234-6550 1 COVER
36 1 234-6579 2 NUT-SPEED
37 1 235-8922 1 COVER
38 1 235-8923 2 CAP
39 1 235-8926 1 VISOR
40 1 235-8928 1 LINER
41 1 235-8929 2 HANDLE
42 1 185-8205 5 CLIP
43 1 235-8950 10 CLIP
44 1 245-7790 2 SCREW-TAPPING
M45 1 128-2135 13 SCREW-TRUSS HEAD (M6X
1X13-MM)
M46 1 128-2136 1 SCREW-TRUSS HEAD (M6X1X16-MM)
47 1 189-2855 1 COVER
48 1 234-6469 1 COVER
M49 1 9X-2042 23 SCREW-TRUSS HEAD (M6X1X12-MM)
M50 1 9X-2044 6 SCREW-TRUSS HEAD (M6X1X16-MM)
M-METRIC PART
870 OPERATOR STATION 1of2 SEBP 4861-02
