CAT 315 Part Manual Page 117

Part Manual
FUEL SYSTEM
262-2261 LINES
GP-FUEL
S/N: CJN1 -UP
PART OF 260-696
0 CHASSIS AR
SMCS-1274 i02791361
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
12 4I-0379 1 VALVE-MANUAL (DRAIN, FUEL TANK)
22 5P-7175 1 FITTING-STRAIGHT
32 7Y-8167 1 GROMMET
42 7Y-8170 1 GROMMET
52 003-7764 2 END-HOSE
61,2 095-1386 9 CLAMP-HOSE
M7 2 135-8573 6 BOLT AS (M12X1.75X25-MM)
82 150-3024 1 ELBOW AS
2 3J-1907 1 SEAL-O-RING
2 5P-4924 1 ELBOW
Y9 2 174-9570 1 FILTER GP-WATER SEP & FUEL (PRIMARY) 84
10 2 177-9778 1BASEAS
2 9S-4167 1 STUD-HOLLOW (1-14X1.47-IN)
11 2 270-9628 1 SHEET AS
E11A 2 3E-8268 TRIM (18-CM)
11B 2 093-2064 1 GROMMET
12 2 273-7765 1HOSE
Y13 2 298-3147 1 VALVE GP-FUEL SHU
TOFF
122
14 1 304-0041 1 BRACKET AS
15 1 307-7879 1HOSEAS
16 2 307-7880 1HOSEAS
17 2 307-7915 1HOSEAS
18 2 307-8125 1 GROMMET
19 1 093-2068 1 GROMMET
20 2 3J-1907 5 SEAL-O-RING
21 1 5I-8307 1 GROMMET
22 1,2 5K-8451 6CLIP
23 1 6D-4636 2CLIP
24 1,2 6K-8178 5CLIP
25 1,2 8T-4121 26 WASHER-HARD (11X21X
2.5-MM THK)
M261,2 8T-4133 1 NUT (M10X1.5-THD)
M271,2 8T-4136 6 BOLT (M10X1.5X25-MM)
M281,2 8T-4137 15 BOLT (M10X1.5X20-MM
)
M29 2 8T-4195 4 BOLT (M10X1.5X30-MM)
30 1,2 9M-8406 8CLIP
31 2 9S-8004 5 PLUG-O-RING
E32 2 5P-1442 HOSE (30-CM)
E32A 1 5P-1442 HOSE (149-CM)
E-ORDER BY THE CENTIMETE
R
M-METRIC PART
Y-SEPARATE ILLUSTRATIO
N
SEBP4861-02 1of3 FUEL SYST EM 87
