CAT 315 Part Manual Page 604

Part Manual
HYDRAULIC SYSTEM
260-8242 LINES
GP-PILOT
–CONTROL PATTERN CHANGE, 2-WAY
S/N: CJN1 -UP
PART OF 259-757
7 VALVE AR-ALT PATTERN CONTROL
AN ATTACHMENT
SMCS-5057, 5059 i02911118
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
I1 1 4I-1037 4 HOSE AS
I2 1 4I-6136 1 HOSE AS
31 4I-9521 4 BAND-MARKER (R
ED, L1)
41,2 4I-9523 4 BAND-MARKER (BLUE, L3)
51,2 4I-9525 4 BAND-MARKER (ORANGE, R1)
61,2 4I-9527 4 BAND-MARKER (GR
EEN, R3)
I7 2 5I-4076 2 HOSE AS
81,2 7K-1181 15 STRAP-CABLE
I9 1 104-8777 1 HOSE AS
I10 2 110-5499 1 HOSE AS
11 1 148-8420 1 TEE AS
1 3K-0360 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 8T-6338 1 TEE-O-RING PORT
12 2 309-5769 1 SWITCH AS-PRESSU
RE (SWING)
2 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
2 9X-3401 2 PIN-CONNECTOR (16
-GA TO 18-GA)
–OR–
2 126-1767 2 PIN-CONNECTOR (14-GA)
13 2 270-5664 1 VALVE GP-PILOT (ALT
PATTERN CONTROL, 2-WAY)
14 1 272-4144 1 GROMMET
15 2 272-4214 1 SUPPORT
I16 2 108-7357 1 HOSE AS
17 1 148-8336 1 CONNECTOR AS
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 6V-8636 1 CONNECTOR
18 2 148-8378 7 ELBOW AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-8724 1 ELBOW
19 2 150-3036 4 ELBOW AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 8T-1905 1 ELBOW
20 2 8T-4121 3 WASHER-HARD (11X21X2.
5-MM THK)
M21 2 8T-4137 3 BOLT (M10X1.5X20-MM)
M22 2 8T-4192 3 BOLT (M12X1.75X25-MM)
23 2 8T-4223 3 WASHER-HARD (13.5X25.5
X3-MM THK)
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
574 HYDRAULIC SYSTEM 1of3 SEBP 4861-02
