CAT 315 Part Manual Page 585

Part Manual
HYDRAULIC SYSTEM
260-8217 LINES
GP-PILOT
–MAIN CONTROL VALVE
S/N: CJN528-UP
PART OF 259-754
7 HYDRAULIC AR
SMCS-5057, 5059 i03183296
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
I1 2 4I-0836 1HOSEAS
22 4I-3941 2 FITTING AS
31 4I-3953 2 GROMMET
I4 2 4I-3988 1HOSEAS
I5 2 4I-3994 1HOSEAS
62 4I-9521 6 BAND-MARKER (RED, L1)
72 4I-9522 6 BAND-MARKER (YELLOW, L2)
82 4I-9523 2 BAND-MARKER (BLUE, L3)
92 4I-9524 2 BAND-MARKER (BROWN, L4)
10 2 4I-9525 6 BAND-MARKER (ORANGE, R1)
11 2 4I-9526 6 BAND-MARKER (WHITE, R2)
12 2 4I-9527 2 BAND-MARKER (GREEN, R3)
13 2 4I-9528 2 BAND-MARKER (PURPLE, R4)
C14 2 320-0150 2HOSEAS
15 1,2 7K-1181 14 STRAP-CABLE
I16 2 7Y-4199 1HOSEAS
17 1 087-4587 2 GROMMET
I18 2 104-8771 2HOSEAS
I19 2 104-8774 1HOSEAS
I20 2 104-8973 1HOSEAS
I21 2 104-8976 1HOSEAS
I22 2 111-6752 1HOSEAS
23 2 133-5813 2 BAND-MARKER (GRAY, P)
24 2 309-5768 2 SWITCH AS-PRESSURE (IMPLEMENT)
(EACH INCLUDES)
2 9X-3402 2 SOCKET-CONNECTOR (16-GA TO 18-GA)
–OR–
2 126-1768 2 SOCKET-CONNECTOR (14-GA)
2 155-2270 1 KIT-CONNECTING PLUG (2-PIN)
(INCLUDES PLUG AS, WEDGE & INTERFACE SEAL)
25 2 221-4807 1HOSEAS
26 1,2 115-8645 5 GUARD
C27 2 148-8336 4 CONNECTOR AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-8636 1 CONNECTOR
29 2 148-8378 2 ELBOW AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 6V-8724 1 ELBOW
30 2 148-8407 2PLUGAS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 9S-4191 1 PLUG-O-RING
31 2 148-8435 4TEEAS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 2 SEAL-O-RING
2 6V-8781 1 TEE-FACE SEAL
32 2 150-3036 3 ELBOW AS
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 6V-8397 1 SEAL-O-RING
2 8T-1905 1 ELBOW
SEBP4861-02 1of4 HYDRAULIC SYSTEM 555
