CAT 315 Part Manual Page 213

Part Manual
ELECTRICAL AND STARTING SYSTEM
251-0542 PANEL
GP-SWITCH
–ENGINE SPEED, START
S/N: CJN1 -UP
CONSOLE
CANNOT BE USED WI
TH 251-0544–PAGE 187
AN ATTACHMENT
TYPE 1
SMCS-1408, 1429, 7332, 7451 i02742287
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 3S-2093 4 STRAP-CABLE
Y2 1 9G-7641 1 SWITCH GP-START (ENGINE, KEY) 207
Y3 1 106-0107 1 SWITCH GP-ROTAR
Y (THROTTLE POSITION)
205
41 170-9324 1 LAMP AS (24-VOLT, 3-WATT)
51 185-9208 1 KNOB AS (THROTTLE POSITION)
61 234-1156 1 COVER
71 234-1158 1 COVER
81 267-7976 1 PANEL
91 251-0543 1 HARNESS AS-CONSO
LE (RH)
1 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
1 155-2270 1 KIT-CONNECTING PL
UG (2-PIN)
1 155-2274 1 KIT-CONNECTING PLUG (6-PIN)
(EACH CONNECTING PLUG KIT INCLUDES PLUG AS,
WEDGE & INTERFACE SEAL)
10 1 096-6166 4 WASHER-HARD (4.5X
9X1-MM THK)
11 1 119-5026 4 SCREW-PAN HEAD (10-16X0.63-IN)
M12 1 6V-9491 4 SCREW-MACHINE (M4X0.7X20-MM)
M-METRIC PART
Y-SEPARATE ILLUSTRA
TION
SEBP4861-02 1of2 ELECTRICAL AND STARTING SYSTEM 183
