CAT 315 Part Manual Page 506

Part Manual
HYDRAULIC SYSTEM
260-8243 LINES
GP-BOOM CYLINDER
–BOOM LOWERING CONTROL
S/N: CJN1 -UP
PART OF 259-757
8, 323-7798 VALVE AR-CHECK & RELIEF
AN ATTACHMENT
SMCS-5057, 5456 i03180328
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 7K-1181 3 STRAP-CABLE
I2 1 196-3369 1 HOSE AS
31 199-1861 1 TUBE AS
41 199-1862 1 TUBE AS
I5 1 199-2013 1 HOSE AS
61 210-2768 1 FITTING
71 221-8859 1 SENSOR AS-PRESSURE (BOOM CYLINDER)
1 3E-3371 1 WEDGE-RECEPTACLE LOCK (3-PIN)
1 3K-0360 1 SEAL-O-RING
1 9X-3401 3 PIN-CONNECTOR (16-GA TO 18-GA)
–OR–
1 126-1767 3 PIN-CONNECTOR (14-GA)
1 171-0596 1 RECEPTACLE AS
Y8 1 285-1685 1 VALVE GP-LOAD CONTROL
(BOOM LOWERING CONTROL, LH)
693
Y9 1 285-1686 1 VALVE GP-LOAD CONTROL
(BOOM LOWERING CONTROL, RH)
695
10 1 296-7057 1 HOSE AS
E17I-7439 GUARD (95-CM)
11 1 302-2988 2 SUPPORT AS
12 1 148-8336 3 CONNECTOR AS
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 6V-8636 1 CONNECTOR
13 1 148-8341 2 CONNECTOR AS
(EACH INCLUDES)
1 3D-2824 1 SEAL-O-RING
1 6V-8713 1 CONNECTOR
1 7J-9108 1 SEAL-O-RING
14 1 148-8371 2 ELBOW AS
(EACH INCLUDES)
1 6V-8397 1 SEAL-O-RING
1 8C-8988 1 ELBOW
15 1 148-8378 3 ELBOW AS
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 6V-8724 1 ELBOW
16 1 148-8433 2 TEE AS
(EACH INCLUDES)
1 6V-8397 2 SEAL-O-RING
1 6V-9836 1 TEE-SWIVEL
17 1 164-5567 2 COUPLER AS-QUICK DISCONNECT
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 6V-3965 1 FITTING (QUICK DISCONNECT)
18 1 1P-3703 2 SEAL-RECTANGULAR
19 1 3J-1907 1 SEAL-O-RING
20 1 6V-0852 2 CAP-DUST
21 1 7J-9108 2 SEAL-O-RING
M22 1 280-2747 8 BOLT-SOCKET HEAD (M10X1.5X60-MM)
E-ORDER BY THE CENTIMETER
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
Y-SEPARATE ILLUSTRATION
476 HYDRAULIC SYSTEM 1of2 SEBP 4861-02
