ELECTRICAL AND STARTING SYSTEM

297-4470 SENSO

R & M TG GP-POSITION

–STICK

S/N: CJN1 -UP

PART OF 330-877

7 BOOM AR, 301-2479, 301-2517 SPECIAL AR

AN ATTACHMENT

SMCS-5736 i02840336

NOTE

REF

GRAPHIC

REF PART NUM BER QTY

PART NAM E

123456(PRODUCT LEVEL

)

SEE

PAGE

Y1 1 169-0417 1 SENSOR GP-POSITION (STICK) 197

21 309-5693 1 LEVER AS

31 309-5694 1 PLATE

41 309-5695 1 ROD AS

M18T-4133 1 NUT (M10X1.5-THD)

M19X-2065 1 NUT (M10X1.15-T

HD)

51 309-5733 1 ROLLER

61 309-5734 1 SPACER (10.8X17.3X12-MM THK)

M7 1 131-3983 4 BOLT-SOCKET HEAD

(M8X1.25X35-MM)

M8 1 8T-1160 1 BOLT-SOCKET HEAD (M10X1.5X50-MM)

91 8T-4121 3 WASHER-HARD (11X21X2.5-MM THK)

M10 1 8T-4195 1 BOLT (M10X1.5X30

-MM)

11 1 8T-4224 4 WASHER-HARD (8.8X16X2-MM THK)

M12 1 8T-4971 2 BOLT (M6X1X30-MM)

13 1 9X-8256 2 WASHER (6.6X12X2

-MM THK)

M-METRIC PART

Y-SEPARATE ILLUSTRATION

GRAPHIC #1 <END> g01418908

192 ELECTRIC AL AND S TARTING SY STEM 1of1 SEBP 4861-02
