CAT 315 Part Manual Page 281

Part Manual
ELECTRICAL AND STARTING SYSTEM
319-1364 WIRIN
G GP- HEAT ER
S/N: CJN1 -UP
AN ATTACHMENT
SMCS-7304 i03146333
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 3S-2093 8 STRAP-CABLE
21 7K-1181 18 STRAP-CABLE
31 116-0114 1 SWITCH AS-MAGN
ETIC (24-VOLT)
(AIR INLET HEAT
ER RELAY)
1 186-3735 2 PIN-CONNECTOR (16-GA TO 18-GA)
1 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEP
TACLEAS&WEDGE)
41 197-4330 1 CONTROLLER-AIR (HEATER)
51 319-1344 1 BRACKET AS
61 319-1346 1 COVER AS
71 319-1348 1 HARNESS AS-CONTROL (ENGINE START, PUMP CONTROL)
81 319-1349 1 CABLE AS
D16V-2369 WIRE (4-GA, BLACK
) (2.9-M)
1 8T-8799 1 BOOT
1 9G-4343 1 TERMINAL (4-GA)
1 5P-3454 1 TERMINAL (4-GA)
91 319-1354 1 CABLE AS
D16V-2369 WIRE (4-GA, BLACK) (0.2-M)
1 9G-4343 2 TERMINAL (4-GA)
10 1 319-1355 1 CABLE AS
D16V-2369 WIRE (4-GA, BLACK) (0.2-M)
1 9G-4343 2 TERMINAL (4-GA)
M11 1 5C-2890 2 NUT (M6X1-THD)
M12 1 5C-9553 1 BOLT (M6X1X16-MM)
M13 1 7X-2619 2 BOLT (M6X1X10-MM)
M14 1 8T-4171 2 BOLT (M6X1X12-MM)
M15 1 8T-4970 2 BOLT (M6X1X14-MM)
16 1 9X-8256 7 WASHER (6.6X12X2-M
MTHK)
D-ORDER BY THE METER
M-METRIC PART
SEBP4861-02 1of2 ELECTRICAL AND STARTING SYSTEM 251
