CAT 315 Part Manual Page 633

Part Manual
HYDRAULIC SYSTEM
302-3258 LINES
GP-PILOT
–SYSTEM 20, WORK TOOL PRIORITY
S/N: CJN1 -UP
PART OF 259-755
7 CONTROL AR-AUXILIARY
AN ATTACHMENT
TYPE 2
SMCS-5057, 5059 i03146252
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
I1 3 4I-1780 1HOSEAS
I2 3 4I-1783 1HOSEAS
32 4I-3941 1 FITTING AS
CI 4 2,3 4I-5906 2HOSEAS
53 4I-9521 2 BAND-MARKER (RED, L1)
63 4I-9522 4 BAND-MARKER (YELLOW, L2)
71,2 4I-9523 6 BAND-MARKER (BLUE, L3)
83 4I-9524 4 BAND-MARKER (BROWN, L4)
93 4I-9525 2 BAND-MARKER (ORANGE, R1)
10 1,2,3 4I-9527 6 BAND-MARKER (GREEN, R3)
CI 11 2 5I-4396 1HOSEAS
12 3 5P-5148 1 STRAP-TIE
C 13 1,2,3 7K-1181 12 STRAP-CABLE
I14 3 087-5303 1HOSEAS
I15 2 087-5762 1HOSEAS
I16 2 087-5766 1HOSEAS
I17 3 104-8771 1HOSEAS
18 2 104-8903 1 GUARD
Y19 2 121-6303 1 VALVE GP-SOLENOID (WORK TOOL PRIORITY) 737
Y20 2 123-2430 1 VALVE GP-SHUTTLE 729
21 1 150-4027 2TEEAS
(EACH INCLUDES)
1 3E-2310 1TEE
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
22 2 164-6874 4 FITTING AS-ELBOW
(EACH INCLUDES)
2 3J-1907 1 SEAL-O-RING
2 085-735
6
1 FITTING
Y23 1 171-0188 1 VALVE GP-SOLENOID
(NEG FLOW CONT, PROPN RED VALVE)
738
I24 2 199-2013 1HOSEAS
C25 3 212-5402 1HOSEAS
Y26 2 226-3109 1 VALVE GP-SOLENOID (NEGATIVE FLOW CONTROL) 739
27 2 260-8071 1HOSEAS
I28 2 266-1293 2HOSEAS
I29 1 266-1389 1HOSEAS
30 2 269-9717 1 PLATE
I31 2 269-9754 1HOSEAS
Y32 2 270-5766 1 VALVE GP-SOLENOID & PRESS REDC
(WORK TOOL CONTROL)
748
I33 1 272-4180 1HOSEAS
34 1,3 275-1442 2 CLIP (TAB)
35 1,3 275-1443 2 CLIP (SLOT)
36 1,3 275-1444 2 GROMMET
37 2 278-6419 1 PLATE
38 3 278-6905 1HOSEAS
39 3 282-7106 1 GROMMET
40 3 282-7113 1 SUPPORT AS
41 3 282-7198 1HOSEAS
42 1 285-2663 1 FITTING AS
1 3J-1907 1 SEAL-O-RING
43 3 286-6560 1HOSEAS
E37I-7439 GUARD (390-CM)
SEBP4861-02 1of6 HYDRAULIC SYSTEM 603
