OPERATOR STATION

164-0497 GUARD

GP-OVERHEAD

S/N: CJN1 -UP

PART OF 178-554

9 GUARD AR-OVERHEAD

AN ATTACHMENT

SMCS-7159 i03253683

NOTE

REF

GRAPHIC

REF PART NUM BER QTY

PART NAM E

123456(PRODUCT LEVEL

)

SEE

PAGE

11 8V-1715 2 SPACER (20.5X35X12-MM THK)

21 167-7141 1 GUARD AS

31 219-0305 1 FILM-WARNING (

NO WELD, NO DRILL, READ OMM)

41 298-4196 1 FILM-CERTIFICATION (OPS GUARD, READ OMM)

61 090-8865 2 SPACER (17X40X3-MM THK)

(WHEN EQUIPPED W

ITH CAB LIGHTS)

-OR-

1 090-8865 3 SPACER (17X40X3-MM THK)

(WHEN EQUIPPED WIT

H PRODUCT LINK)

-OR-

1 090-8865 1 SPACER (17X40X3-MM THK)

(WHEN EQUIPPED WITH

CAB LIGHTS AND PRODUCT LINK)

M7 1 7X-2559 2 BOLT (M16X2X160-MM)

M8 1 8T-4174 2 BOLT (M16X2X120-MM)

91 9X-8257 4 WASHER (17.5X30X3.

5-MM THK)

M-METRIC PART

964 OPERATOR STATION 1of2 SEBP 4861-02
