CAT 315 Part Manual Page 345

Part Manual
FRAME AND BODY
267-6832 GEAR &
BEARING GP-SWING
S/N: CJN1 -UP
PART OF 260-697
5 FRAME AR-UNDERCARRIAGE
SMCS-7063 i02814406
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 2Y-5503 1CORK
21 4I-7444 1BOOT
31 4I-7446 1 GASKET
41 4I-7511 1 RETAINER
51 4I-7512 1 CLAMP-HOSE
61 5K-9243 2 ELBOW-FLARED
71 102-6449 1TUBEAS
81 171-9464 68 SPACER (20.6X38X6-MM THK)
91 267-6831 1 GEAR & BEARING GP
-SWING
1 3B-8489 1 FITTING-GREASE
E1148-4685 SEAL (335-CM)
1 229-1081 2 SEAL-DUST
10 1 095-7993 1 DOWEL
11 1 148-4703 1 COVER
12 1 148-4704 1 GASKET
13 1 3B-8489 1 FITTING-GREASE
14 1 4I-7326 1 STRIP
15 1 4N-9170 2CLIP
M16 1 6V-3532 36 BOLT (M20X2.5X60-MM)
M17 1 8T-0362 32 BOLT (M20X2.5X110-MM)
18 1 8T-4121 14 WASHER-HARD (11X2
1X2.5-MM THK)
M19 1 8T-4136 12 BOLT (M10X1.5X25-MM)
M20 1 8T-4137 2 BOLT (M10X1.5X20-MM)
M21 1 8T-4199 2 BOLT (M8X1.25X12-M
M)
B22 1 1U-8846 SEALANT-GASKET
B-USE AS REQUIRED
E-ORDER BY THE CENTIMETER
M-METRIC PART
SEBP4861-02 1of2 FRAME AND BODY 315
