CAT 315 Part Manual Page 504

Part Manual
HYDRAULIC SYSTEM
260-8209 LINES
GP-BOOM CYLINDER
S/N: CJN1 -UP
PART OF 259-754
7 HYDRAULIC AR
SMCS-5057, 5456 i02844917
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 093-1296 1 CLAMP
21 099-5408 1 CLAMP
31 106-8715 2 ELBOW AS
(EACH INCLUDES)
1 3D-2824 1 SEAL-O-RING
1 6V-9746 1 SEAL-O-RING
1 8C-8400 1 ELBOW
I4 1 184-9543 4 HOSE AS
51 187-5873 1 TUBE AS
61 187-5874 1 TUBE AS
71 266-7940 1 ROD AS
1 225-4539 1 WASHER-SPECIAL
81 266-7941 1 BRACKET AS
91 268-5145 1 ELBOW AS
1 3D-2824 1 SEAL-O-RING
1 6V-9746 1 SEAL-O-RING
1 194-9041 1 ELBOW
10 1 269-9799 1 SUPPORT AS
11 1 278-6495 1 HOSE AS
12 1 148-8336 1 CONNECTOR AS
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 6V-8639 1 CONNECTOR (SEAL)
13 1 148-8340 1 CONNECTOR AS
1 3K-0360 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 6V-8639 1 CONNECTOR
14 1 148-8341 2 CONNECTOR AS
(EACH INCLUDES)
1 3D-2824 1 SEAL-O-RING
1 6V-8713 1 CONNECTOR
1 7J-9108 1 SEAL-O-RING
15 1 148-8347 2 ELBOW AS
(EACH INCLUDES)
1 3D-2824 1 SEAL-O-RING
1 6V-9007 1 ELBOW
1 6V-9746 1 SEAL-O-RING
16 1 148-8361 1 ELBOW AS
1 3J-7354 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 6V-9200 1 ELBOW
17 1 148-8365 1 ELBOW AS
1 3J-1907 1 SEAL-O-RING
1 6V-8398 1 SEAL-O-RING
1 8T-6876 1 ELBOW (90-DEG)
18 1 148-8444 1 TEE AS-SWIVEL
1 6V-8398 2 SEAL-O-RING
1 6V-9837 1 TEE-SWIVEL
19 1 7J-9108 8 SEAL-O-RING
M20 1 8T-4192 4 BOLT (M12X1.75X25-MM)
21 1 8T-4223 6 WASHER-HARD (13.5X25.5X3-MM THK)
M22 1 8T-4648 1 BOLT (M12X1.75X70-MM)
M23 1 8T-4910 1 BOLT (M12X1.75X60-MM)
24 1 9F-2167 1 SCREW-PURGE (3/8-24X1.164-IN)
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
474 HYDRAULIC SYSTEM 1of2 SEBP 4861-02
