ELECTRICAL AND STARTING SYSTEM

299-2697 WIRIN

G GP- CAB

–ACCUGRA DE READY

S/N: CJN1 -UP

PART OF 301-247

9, 301-2517, 330-8775 SPECIAL AR

AN ATTACHMENT

SMCS-1408, 7301 i02840817

NOTE

REF

GRAPHIC

REF PART NUM BER QTY

PART NAM E

123456(PRODUCT LEVEL

)

SEE

PAGE

12 3S-2093 9 STRAP-CABLE

22 7K-1181 22 STRAP-CABLE

32 113-8491 1 FUSE (15-AMPER

E) (ACCUGRADE, SOLENOID RESISTOR)

42 204-1790 3 RESISTOR AS

52 283-3074 1 SWITCH AS-TOGGLE (ACCUGRADE BACKUP)

62 299-2701 1 HARNESS AS-CAB

72 299-2841 1 HARNESS AS-SOLENOID

82 299-2952 1 SHEET AS

M9 2 5C-2890 3 NUT (M6X1-THD)

M10 2 7X-2619 6 BOLT (M6X1X10-MM)

11 2 9X-8256 9 WASHER (6.6X12X2-MM THK)

M-METRIC PART

GRAPHIC #1 g01421082

SEBP4861-02

1of2 ELECTRICAL AND STARTING SYSTEM 225
