CAT 315 Part Manual Page 849

Part Manual
WORK TOOLS
327-3614 BUCKE
T GP-G ENER AL PURPOSE
S/N: CJN1 -UP
617-MM (24-IN)
WIDE X 0.4-CU M (0.5-CU YD) CAPACITY. K-80 ADAPTERS, (3X)
AN ATTACHMENT
SMCS-6101 i03093721
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
Y 327-3615 1 BUCKET AS-GENERAL PURPOSE 802
Y 2C-9589 1 PIN GP-BUCKET 823
Y 7Y-0729 1 SIDECUTTER GP 825
Y 229-6966 3 TIP GP-PENETRATION PLUS (K-80) 834
Y-SEPARATE ILLUSTRATION
<END>
327-3617 BUCKET GP-GENERAL PURP OSE
S/N: CJN1 -UP
770-MM (30-IN) WIDE X 0.5-CU M (0.6-CU YD) CAPACITY. K-80 ADAPTERS, (4X)
AN ATTACHMENT
SMCS-6101 i03095132
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 327-3618 1 BUCKET AS-GENERAL PURPOSE 803
Y 2C-9589 1 PIN GP-BUCKET 823
Y 7Y-0729 1 SIDECUTTER GP 825
Y 229-6966 4 TIP GP-PENETRATION PLUS (K-80) 834
Y-SEPARATE ILLUSTRATION
<END>
327-3620 BUCKET GP-GENERAL PURP OSE
S/N: CJN1 -UP
922-MM (36-IN) WIDE X 0.6-CU M (0.8-CU YD) CAPACITY. K-80 ADAPTERS, (5X)
AN ATTACHMENT
SMCS-6101 i03095186
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 327-3621 1 BUCKET AS-GENERAL PURPOSE 804
Y 2C-9589 1 PIN GP-BUCKET 823
Y 7Y-0729 1 SIDECUTTER GP 825
Y 229-6966 5 TIP GP-PENETRATION PLUS (K-80) 834
Y-SEPARATE ILLUSTRATION
<END>
SEBP4861-02 WORK TOOLS 819
