CAT 315 Part Manual Page 290

Part Manual
ELECTRICAL AND STARTING SYSTEM
259-5160 WIRIN
G GP-P LATF ORM
S/N: CJN1 -UP
PART OF 259-719
3 OPERATOR AR
SMCS-1408 i02599637
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
12 3E-5169 1 GUARD-SWITCH
21 3S-2093 3 STRAP-CABLE
31 7G-1060 1 STRAP AS-GROUN
D
41,2 7K-1181 14 STRAP-CABLE
51 111-4836 4 CLIP
61 111-4838 2 CLIP
71 111-4839 2 STRAP
81 116-0118 12 CLIP
92 234-1122 1 COVER
10 1 251-0299 1 HARNESS AS-SWITCH (SECONDARY SHUTDOWN)
1 243-4505 1 RECEPTACLE AS-CONNECTOR (2-PIN)
11 1 259-5297 1 HARNESS AS-PLATF
ORM
1 102-8802 6 KIT-RECEPTACLE (2-PIN)
1 102-8804 1 KIT-RECEPTACLE (4-PIN)
(EACH RECEPTACLE K
IT INCLUDES RECEPTACLE AS &
WEDGE)
1 3S-2093 19 STRAP-CABLE
E1119-3662 TUBE-HEAT SHRINK (10.85-MM DIA) (7-CM)
E1125-7874 TUBE-HEAT SHRINK (
5.72-MM DIA) (20-CM)
E1125-7875 TUBE-HEAT SHRINK (7.44-MM DIA) (45-CM)
1 153-2620 1 PLUG AS-CONNECTOR (54-PIN, BLACK)
1 163-6759 1 SEAL
1 155-2270 10 KIT-CONNECTING PLUG (2-PIN)
1 155-2271 1 KIT-CONNECTING PLUG (4-PIN)
(EACH PLUG KIT INCLU
DES PLUG AS, WEDGE &
INTERFACE SEAL)
1 197-4385 3 DIODE
1 230-4009 3 PLUG AS-CONNECTOR (12-PIN)
1 230-4011 3 PLUG AS-CONNECTOR (2
-PIN)
1 230-5010 3 PLUG AS-CONNECTOR (6-PIN)
1 239-7352 1 PLUG AS-CONNECTOR (6-PIN)
1 243-4505 1 RECEPTACLE AS-CONNE
CTOR (2-PIN)
1 243-4507 1 RECEPTACLE AS-CONNECTOR (4-PIN)
1 243-4508 4 RECEPTACLE AS-CONNECTOR (6-PIN)
1 243-4509 1 RECEPTACLE AS-CONNE
CTOR (8-PIN)
1 243-4510 2 RECEPTACLE AS-CONNECTOR (12-PIN)
1 247-2693 1 RECEPTACLE AS-CONNECTOR (6-PIN)
12 2 275-6810 1 RECEPTACLE AS
2 134-3297 1 SEAL
2 163-6773 1 PLUG-SEAL
M13 2 095-0728 2 SCREW-MACHINE (M4X0.
7X12-MM)
14 2 096-6166 2 WASHER-HARD (4.5X9X1-MM THK)
15 2 4D-1836 1 SWITCH AS-TOGGLE (SECONDARY SHUTDOWN)
M16 1 7X-2621 6 BOLT (M10X1.5X12-MM)
17 1 8T-4121 13 WASHER-HARD (11X21X2.5-MM THK)
M18 1 8T-4137 7 BOLT (M10X1.5X20-MM)
E-ORDER BY THE CENTIMETER
M-METRIC PART
260 ELECTRIC AL AND S TARTING SY STEM 1of3 SEBP 4861-02
